Tunnel Hot air Circulating Pharmaceutical Processing Machines Heating and Sterilizing Oven for Bottles
Product Details:
| Place of Origin: | China |
| Brand Name: | LTPM CHINA |
| Certification: | CE Certificate |
| Model Number: | DMH-A3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case |
| Delivery Time: | 45 days |
| Supply Ability: | 25 sets/month |
|
Detail Information |
|||
| Total Power: | 18kw | Heating Power: | 15kw |
|---|---|---|---|
| Blast Power: | 1.5kw | Material: | 304/316L Stainless Steel |
| Accessories: | SIEMENS, MITSUBISHI, PALL | ||
| High Light: | pharmaceutical process equipment,pharma machinery |
||
Product Description
Tunnel Hot-air Circulating Heating and Sterilizing Oven for Bottles
I. Technical Parameters
| Model | Total power |
Heating power
|
Blast power
|
Exclude moisture power
|
Studio size
|
Overall dimensions
|
Purify level |
| DMH-A3 | 18 KW | 15 KW | 1.5 KW | 0.37 KW | 900×800×1200 | 1600×1240×1950 | Hundred |
II. Basic Functions and Configuration
1.Chamber and all parts that may contact the staffs for sterilization all adopts 304 stainless steel;
2.Outside adopts 304-2B stainless steel material, using new manufacturing craft, which could meet GMP requirement and making the external more beautiful;
3.Special heat thermal method, which ensure product surface temperature≤room temperature+15℃
4.Chamber adopts special sealing welding method, chamber corner is circular arc transition, with no cleaning dead corner.
III. DMH-A3 Double Door Hundred Level Purification Sterilizing Oven Configuration Table
| No. | Part name | Specifications and Model | Quantity | Note |
| 1 | Shell | Stainless steel 304 1.5mm | Complete machine | Matt surface |
| 2 | Liner | Stainless steel 304 1.5mm | Complete machine | Matt surface Tight weld of angle R |
| 3 | Convection wall | Stainless steel 304 1.5mm | Complete machine | |
| 4 | Heating pipe | Stainless steel 304 | 12 | 220V 1.25KW/Root |
| 5 | Insulation | Silicate cotton | 8m3 | Produced in Wuxi |
| 6 | Heat resisting high efficiency filter | 1200×750×150 | 1 | Changzhou |
| 7 | Heat resisting high efficiency filter | 150×150×150 | 2 | Changzhou |
| 8 | Circulation fan | 1.5KW | 1 | Nanjing high temperature air blower factory |
| 9 | Cooling fan | 0.18KW | 1 | Nanjing high temperature air blower factory |
| 10 | Moisture fan | 0.18KW | 1 | Nanjing high temperature air blower factory |
| 11 | Shelving | Suitable for user requirements | 1 | Homemade |
| 12 | Door seal | White heat resisting silicone rubber | 20m | Changzhou silicone rubber factory |
| 13 | Door-pressure hand | 4 | Homemade | |
| 14 | Printer | 1 | Beijing | |
| 15 | Touch screen | 1 | DELTA | |
| 16 | Program controller | 1 | DELTA | |
| 17 | Breaker | DZ47-63-3P32A | Chint Electric | |
| 18 | Differential gauge | 500Pa | Dewey Instrument | |
| 19 | Control apparatus | 1 | Chint Electric |
