Glue Sealing Box Automatic Packaging Machine Robatech Hotmelt Sealing System

Glue Sealing Box Automatic Packaging Machine Robatech Hotmelt Sealing System

auto cartoning machine

automatic carton packing machine

Place of Origin:

China

Brand Name:

LTPM China

Certification:

CE, GMP, SGS, BV

Model Number:

ZH-100

Contact Us

Request A Quote
Product Details
Product Description

Glue Sealing Box Automatic Packaging Machine Robatech Hotmelt Sealing System


Quick Detail:


1. Steady production speed: 50-100 cartons/min
2. Grammage: Between 60-70g/m2
3.Size range: (80-250) ×(90-170)mm (L×W)
4. Fold range: (1-4 )fold
5. Standard power supply: 220V – 50Hz
6. Power consumption in KW: 0.75


Description:


1. Half facility for air pressure and vacuum protection, when caster opened, the halt facility will     be checked automatically for operating safety of the machine.
2. It is easy, convenient and quick to change and adjust product size by hand wheel on                   instrument panel.
3. Variable frequency speed regulation, PLC automatic control, Operating on the touch screen,     words and numeric display, easy to operate, stable coefficients in operation.
4. Overload protection for principal driving, indication of failure diagnosis, and automatic halt       of failure


Applications:


This machine is suitable for packing AL/PL Blister, bottle, Pillow Type Bags and other related similar content compact automatic leaflet folding, box opening and loading, batch number embossing as well as sealing technology processes. (Options hot-glue device extra)


Specifications:




Model ZH-100
Weight in kg 1100
Steady production speed 50-100 cartons/min
Grammage Between 60-70g/m2
Size range (80-250) ×(90-170)mm (L×W)
Fold range (1-4 )fold
Notice: The leaflet can be folded by the machine
Grammage Between 250-350g/m2
Carton Size mm (12-125)×(12-85)×(12-50)mm
Standard power supply 220V – 50Hz
Power consumption in KW 0.75
Air consumption 120-160L/min
Compressed Air Pressure 0.6MPa
Noise <70 dB



Competitive Advantage:


1. Continuous mechanical feeding materials and carton, and working of each function part are in harmony, stable and reliable.
2. When material do not reach correct position, the pusher has an alarm and half facility for that, in order to ensure good quality of carton packaging and safety in operation effectively.
3. Constantly moving carton-opening mechanism and pulling carton-opening mechanism are more stable and reliable.
4. Vibrating material categorizing and feeding mechanism is stable and reliable.
5. Half facility for air pressure and vacuum protection, when caster opened, the halt facility will be checked automatically for operating safety of the machine.
6. It is easy, convenient and quick to change and adjust product size by hand wheel on instrument panel.
7. Variable frequency speed regulation, PLC automatic control, Operating on the touch screen, words and numeric display, easy to operate, stable coefficients in operation.
8. Overload protection for principal driving, indication of failure diagnosis, and automatic halt of failure.




Hot Glue System(Robatech):
Glue Sealing Box Automatic Packaging Machine Robatech Hotmelt Sealing System 0
Glue Sealing Box Automatic Packaging Machine Robatech Hotmelt Sealing System 1
