Product Details:

Place of Origin: China
Brand Name: LTPM China
Certification: CE, GMP, SGS, BV
Model Number: ZH-130

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: Export Standard Wooden Case
Delivery Time: 25days
Payment Terms: T/T, L/C, D/P
Supply Ability: 25 sets/Month
Get Best Price Contact Now

Detail Information

Packaging Material: Paper Application: Food, Beverage, Chemical, Cigarettes, Tobacco
Driven Type: Electric Dimension(L*W*H): 3600*1200*1700mm( L*W*H)
Weight: 1300kg Working Pressure: ≥0.6mpa
Certification: CE, ISO Capacity: 30-130 Cartons/min
High Light:

30 Cartons/Min Automatic Cartoning Machine

,

PLC Automatic Cartoning Machine

,

GMP Integrated Automatic Cartoning Machine

Product Description

30 Cartons/Min Paper Tissue Automatic Cartoning Machine PLC Control

ZH-130 Automatic Easy operaion High Speed Paper Tissue Cartoning Machine



Our ZH-130 high speed paper tissue cartoning machine suitable
for pack paper tissue in cartons and seal, Also have other model machine suitable
for cartoning (encase) bottle, pouchs, vials, medicine, cosmetis, condom, food, tube,
ointment,wrapped products and daily product.The machine finished running by a series of photo-electro controller to make the machine stability and guarantee the packing quality. The machine can finish all jobs automatically such as leaflet folding, carton opening automatically,
the stuff cartoned, bitch number printing, carton sealing and so on(also can use hot melt glue). It can
be used alone, or be linked with the other device, to be a production line. Its and ideal cartoning machine.



Technical Parameters

Description Automatic cartoning machine
Model ZH-Series Cartoning machine
Speed 50-80 boxes/min
Carton specification Paper material 250-400g/m2 ( need flat surface)
Box size L*W*H(100-240)*(15-150)*(25-85)mm
Power supply 220V/380V,50HZ. Main motor 1.5kw
Dimension 3600*1200*1700mm( L*W*H)
Weight 1300kg
Air supply ≥0.6Mpa
Air consumption 20m3/H
Glue machine China Jingtai(optional )

Features

1. Japan Omron PLC control

2. Japan Omron inverter

3. Japan Omron touch screen

4. Automatic stop when machine is overload

5. Automatic reject lacking of package product and leaflet

6. Automatic trouble display, alarm and counting

7. Stable performance, operaion is easy



Equipment Advantages
1, Integrated with box opening, box loading, box folding, and box sealing, compact and reasonable design, simple operation, and easy maintenance.
2, Can be added before and after the equipment, automatic feeding, automatic under the tray, instructions, print the word code flow number, pick waste, and other functions.
3, It can be quickly adjusted by dial scale within the same equipment to achieve multi-specification use.
4, SUS304 stainless steel is used for the contact part with products.
5, High degree of automation: PLC programmable control system, the human-machine interface shows the speed of carton loading, quantity, automatic alarm for lack of carton, no product not to open the carton, failure reason and other parameters.
6, The transmission and friction parts are strictly following the standard implementation, less wear and tear in the later stage, reducing the replacement of accessories.

Machine Details

30 Cartons/Min Paper Tissue Automatic Cartoning Machine PLC Control 0

30 Cartons/Min Paper Tissue Automatic Cartoning Machine PLC Control 1

30 Cartons/Min Paper Tissue Automatic Cartoning Machine PLC Control 2

Product Application
Mainly applicable to: automatic boxing of medical masks, food, medical supplies, toys, stationery, auto parts, cosmetics,hardware, daily necessities, and other small products

30 Cartons/Min Paper Tissue Automatic Cartoning Machine PLC Control 3
