Liquid Paste Powder Or Granule Automated Packaging Machine
Product Details:
| Place of Origin: | Zhejiang Province,China |
| Brand Name: | LTPM CHINA |
| Certification: | CE, GMP, SGS, BV |
| Model Number: | RotaTop-Series |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Export Standard Wooden Case |
| Delivery Time: | 25 days |
| Payment Terms: | L/C, D/A, D/P, T/T, MoneyGram |
| Supply Ability: | 45 sets/month |
|
Detail Information |
|||
| Working Position: | Eight-working Position | Pouch Material: | Laminated Film PE、PP |
|---|---|---|---|
| Pouch Pattern: | W:100-210mm L:100-350mm | Filling Scope: | 10-5000g（ The Screw Attachment Is To Be Changed） |
| Speed: | 10-45pouches/min（The Speed Depends On The Product Status And Flling Weight）） | Voltage: | 380V 3phase 50HZ/60HZ |
| High Light: | Granule Automated Packaging Machine,Premade Sachet Automated Packaging Machine,Automated Premade Sachet Packaging Machine |
||
Product Description
Liquid Paste Powder Or Granule Automated Packaging Machine
Automatic Premade Sachet/Bag/Pouch Filling Sealing Packaging Machine
For Packing Liquid Paste Powder Or Granule
Machine introduction:
Rotary packing machine is developed for premade pouch, stand-up pouch with or without zipper. It is suitable for packing product of powder, irregular shape, thick liquid and liquid, such as gourmet powder, chicken powder, seasoning powder, candy, fruits, nut, pet food, roasted seeds, puffed food, frozen food, small hardware and hand sanitizer.
Option Part of Weighing&Packing System
*Z Type Bucket Elevator--- --------------------------for conveying material( Not for Powder)
*Multihead Weigher( 10head, 14head, 20head...) ---------------for weighing(not powder)
*Screw Conveor & Auger Filler---------------------This is for Powder material Conveying
*Working Platform 304 stainless steel-------------------------------for supporting equipment
*Finished Product Conveyor------------for conveying and collecting of finished product.
Working Process:
1. Giving bag:Power on, suction tip adsorbs the bag, the arm folder clamps the dial folder on the first working position.
2.Coding: The machine run to the second working position, it codes the bag.
3. Opening bag:The machine run to the third working position, it opens the bag.
4.Filling: The machine runs to the fourth working position, it fills the bag.
5.Sealing: The machine runs to the fifth working position, it checks if the bag is filled with material, then it seals the bag.
6.Forming & output packages: The machine runs to the sixth working position, it cools the bag mouth and forms& output packages. The above process carried out simultaneously by cycle
Technical Parameters:
