Automatic High Speed Rotary Tablet Compression Machine In Tablet Press For Caplets
Product Details:
| Place of Origin: | China |
| Brand Name: | LTPM China |
| Certification: | CE |
| Model Number: | ZP-31D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case |
| Delivery Time: | In 25 days after receiving the deposit |
| Payment Terms: | 30% TT as deposit and 70% before shipping |
| Supply Ability: | 25 sets/Month |
|
Detail Information |
|||
| Capacity: | 45,000-110,000tablets/hour | Material Consist: | Painted Matel |
|---|---|---|---|
| Max. Thickness: | 6mm | Max.Diameter: | 12mm |
| Max.Pressure: | 40KN | Power: | 2.2Kw |
| High Light: | rotary tablet compression machine,rotary tableting machine |
||
Product Description
Automatic Rotary Tablet Press Machine In Tablet Press For Caplets
Scope of application
New type rotary tablet press gives you better quality and price, automatic tablet press for pressing granular raw materials into
This machine is a single-press type, continuous automatic tablet press for pressing granular raw materials into tablets. It is mainly used in pharmaceutical industry and also the chemical, food, electronic, plastic and metallurgical industries.
Full Features
1. The outside part of the machine is fully-enclosed, and it is made of stainless steel, meeting the GMP requirement.
2. It has transparent windows, so that press condition can be observed clearly and the windows can be opened. Cleaning and maintenance are easier
3. The machine can press not only round tablets, but also different geometrical shape tablets, double-layered and annular tablets; the tablets may have the impressed letters on both sides
4. All the controllers and devices are located in one side of the machine, so that it can be easier to operate
5. An overload unit is included in the system to avoid the damage of the punches and apparatus, when overload occurs
6. The machine's worm gear drive adopts fully-enclosed oil-immersed lubrication with long service-life, preventing cross pollution.
| Main Technical Data: | |||
| Stations (unit) | 31 | Thickness of the die (mm) | 28 |
| Maximum compression (KN) | 80 | The diameter of the circle of the central pitch of upper &lower punches on the turret | 320mm |
| Max. Diameter of tablet to be produced (mm) | 13 | Rotary speed of the turret (rpm) | 10-35 |
| Max. Filling depth (mm) | 15 | Capacity of the tablets (tablets/hour) | 150,000 |
| Max. Thickness of tablet (mm) | 6 | Area to occupy (mm 2 ) | 1500*1300*1650mm |
| Diameter of the upper/lower shank (mm) | 32 | Height of the machine (mm) | 1650 |
| Length of the upper shank (mm) | 175 | motor power (kw) | 3 |
| Length of the lower shank (mm) | 183 | Net weight of the machine (kg) | 1.8 |
| Diameter of the die (mm) | 36 | ||
