    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE
    Model Number: ZP-35D

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiation
    Packaging Details: Wooden Case
    Delivery Time: In 25 days after receiving the deposit
    Payment Terms: 30% TT as deposit and 70% before shipping
    Supply Ability: 25 sets/Month
    Contact Now
    Detailed Product Description
    Usage: Round Tablets,square,oval,ring Or Other Irregular Shape. Power Supply: 380V 50Hz Three Phase (depend On Your Requirement)
    Power: 6Kw Max.Pressure: 80KN
    Max.Diameter: 13mm Max. Thickness: 7mm



    ZP-35D GMP Model Rotary Tablet Pressing Machine,Tablet pressing machine,D Tooling Tablet Pressing Machine





    Product Description



    This machine is a double press automatic rotation for shape-pressing equipment, which have the function of press the grain material or powders to be round or irregular shape tablets, such as candy, calcium tablets double-sides with letter printing and etc. which widely suitable for the Industries of pharmaceutical, Chemical, Foodstuff, Plastic Electronic, Powder Metallurgy and so on.





    Functions



    1. The material of the machine is made of stainless steel with totally closed, the surface of turntable deal with polished and prevent cross pollution which meet the GMP standard.

    2. It is equipped with Organic-glass perspective window for tablet producing observation. Each perspective window could be fully opened and easy for cleaning and maintenance.

    3. It is adopts the import Frequency Timing with Electromagnetism Clutch.

    4. Driving system is equipped with oil box and running under oil, easy for heat dissipation and wear-resistance.

    5. It is equipped with Dust Collector as well, which avoid the dust emission, and recycle to save dust.





    Technical Data



    Stations (unit) 35
    Maximum compression (KN) 80
    Max. Diameter of tablet to be produced (mm) 13
    Max. Filling depth (mm) 15
    Max. Thickness of tablet (mm) 6
    Thickness of the die (mm) 26
    The diameter of the circle of the central pitch of upper &lower punches on the turret 320mm
    Rotary speed of the turret (rpm) 14-35
    Capacity of the tablets (max ten thousand tablets/hour) 60,000-147,000pcs
    Area to occupy (mm 2 ) 930x950

















    6Kw Power GMP Model Pharma Equipment D Tooling Tablet Pressing Machine















    Our Services



    1. we have seven technicians who gets passport ready to travel all over world to offer service to you.

    2. We have 24hours hot line for Technical Support.

    3. We get 18hours internet line for technical support.

    4. Video camera in workshop to help you adjust and solve machine problem in working situation.

    5. We have Technical Support in below Foreign Cities:

    California (commission worker), Manila and Davao (Distributor), Lima (Agent), Ho Chi Ming and Hanoi (Agent), Dhaka (Agent), Lahore (Distributor)
