Name: Semi - Automatic Bottle Cartoning Machine Pharmaceutical Machine ≤80db
Brand: Leadtop Pharmaceutical Machinery
SKU: ZH-50
Price: 13,484.00 USD
Availability: InStock

Home > products > Automatic Cartoning Machine >

Semi - Automatic Bottle Cartoning Machine Pharmaceutical Machine ≤80db

cartoning equipment

automatic carton packing machine

Place of Origin:

China

Brand Name:

LTPM CHINA

Certification:

Model Number:

ZH-50

Request A Quote

Semi - Automatic Bottle Cartoning Machine Pharmaceutical Machine ≤80db

Product Details

Packing Speed:

20-50 Cartons/min

Carton Gram Requirements:

250-350g/m3

Motor Power:

1.5KW

Machine Noise:

≤80dB

Air Pressure:

0.5-0.8 Mpa

Air Consumption:

150L/min

Multi Bottle Cartoning Machine With Servo-driven Clamps And Dual-row Diversion For Efficient Packaging Of Various Bottle Types

Get Best Price

Big Size Cartoner With 8-station Quick-change System For Fast Packaging Of Large Boxes Up To 200x130mm

Get Best Price

Customized Cartoning Machine With 8-station Design And Quick-change System For High-speed Top Loading Packaging

Get Best Price

1450KG Automatic Cartoning Equipment With Touch Screen Packaging Size H15-60mm

Get Best Price

86-0577-65158955

info@chinaleadtop.com

86-0577-65158944

Contact Now

Product Description

ZH-50 Cheap Semi-Automatic Bottle Packaging Machine

Application:

This machine is suitable for sachet, pouch, soft al/al strips, wound plaster, ointment plaster, facial mask plaster, coffee bag into carton. On line product feeding and detecting, leaflet fold (1-4folds) and feeding, leaflet detecting, canton opening and forming, products and leaflet push into carton, printing batch number, sealing carton with tuck-in or hot melt glue device. Automatically reject lacking of leaflet or product and finished product out.

Main Technical Data:

Model	ZH-50
Packing speed	20-50 Cartons/min
Carton size range	L(40-125)mm×W(12-80)mm×H(12-80)mm
Carton gram requirements	250-350g/m3
Motor power	1.5KW
Power supply	Three phase 380V 50Hz
Machine noise	≤80dB
Air pressure	0.5-0.8 Mpa
Air consumption	150L/min
Dimension	1100×1500×1900 mm
Weight	250Kg

Semi - Automatic Bottle Cartoning Machine Pharmaceutical Machine ≤80db 0

Feature:

1. It is specially design to pack small quantities multi size box.

2. With low cost and only require small area. It is suitable for various sizes of box. The machine is a vertical type with multiple function and require a short time to change mould.

3. 304 stainless steel case

4. Advanced PLC Control System Combined with 5.7” Colorful Touch Screen Control Panel , can easily set and change the packing parameters.

Feature:

Main Motor	R17DM80N4 0.75Kw/220V	Germany SEW
Frequency Converter	VLT2907PT4	Denmark Danfoss
Touch screen	GP37WZ-BG41-24V	Japan Proface
PLC	S7-200 CPU224	Germany Siemens
Standard cylinder	CDT2B16-100	Japan SMC
Power Switch	T0-2-1/EA	Germany Queensway Moeller

Semi - Automatic Bottle Cartoning Machine Pharmaceutical Machine ≤80db 1
