Clean Bench Automatic Round Tube Bottle Filling Labeling Machine Reagent Electric Vial
|Place of Origin:||China|
|Brand Name:||LTPM China|
Payment & Shipping Terms:
|Minimum Order Quantity:||1set|
|Packaging Details:||Export Standard Wooden Case|
|Payment Terms:||L/C, T/T|
|Automatic Grade:||Automatic||Tube Length:||50-300mm (customizable)|
|Filling Accuracy:||≤±1%||Safety Protector:||Available|
|Motor:||1.5kw||Tube Material:||Plastic Tube, Laminated Tube|
|Operation System:||Touch Screen|
Bottle Filling Labeling Machine,
Clean Bench Automatic Tube Filling Machine,
Reagent Tube Electric Vial Filling Machine
Filling on conveyor to ensure the capacity.
To fill different volume, it just need to set the revolution of the servo motor on the Touch screen.
The Filling nozzles are diving into container to fill and moving up slowly to avoid bubbling.
Under the filling nozzles, there are no enough number containers will no filling.
And the nozzles are designed to ensure no drop leak.
The noise level of the machine is about 70-80 decibel.
Weight:about 500kg Power:220V/3KW
Food standard viton is made for the sealing parts ( bearing causticity and durable)
l The volume is adjustable
l Servo motor control the peristaltic pump
l It is applicable for different bottle sizes and shapes by adjusting and changing some parts.
l The filling nozzles is optional from 1 to 16 according to the capacity.
l The volume is optional from 0.3ml to 1000ml
v Our advantages:
l 2mm thick SUS304 machine frame.
l SIEMENS PLC and touch screen; Mitsubishi inverter and Schneider electrical elements.
l With mechanical arm to take and put plugs and caps.
l Magnetic torque capping head without damage of caps.
l Stable and reasonable design structure.
