Automatic Tube Filling And Sealing Machine

Best Quality CE Approved High Speed New Design Hot Selling Automatic Soft Tube Filling and Sealing Tube Filling Machine

Best Quality CE Approved High Speed New Design Hot Selling Automatic Soft Tube Filling and Sealing Tube Filling Machine

Brand Name:	LTPM China
Model Number:	LTRG-Series
MOQ:	1set
Price:	Negotiation
Payment Terms:	L/C, T/T
Supply Ability:	15Set/Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Automatic Grade:

Automatic

Voltage:

380(220)V/50Hz

Material:

SUS 304/316L

Production Capacity:

25-40 Pcs /min

Motor:

1.5kw

Tube Height:

50-250mm

Weight:

300kg

Dimension(L*W*H):

1500*700*1800mm

Packaging Details:

Export Standard Wooden Case

Supply Ability:

15Set/Month

Highlight:

CE approved automatic tube filling machine

high speed tube sealing machine

soft tube filling and sealing equipment

Product Description

Feature highlights

The Automatic Tube Filler and Sealer is designed for efficient filling and sealing of semi-fluid materials like cosmetics, beverages, and chemicals. With a capacity of 1800-3000 units/hour and adjustable filling accuracy up to 1%, it ensures reliable performance for manufacturing plants. Its compact dimensions (2440x900x2180mm) save space while the electric-driven system delivers energy-efficient operation. Engineers are available for overseas service, ensuring seamless integration and support. The machine's durable construction and user-friendly interface simplify maintenance and handling.

Features

Compact Design

Automatic Tube Loader Feeding Tubes

Driving Parts Fully-closed

Intelligent Temperature Control and Cooling System

Easy to Operate and Adjust

316L Stainless Steel Contact Parts to meet GMP Standard

Safety Interlock Shutdown when Door is Open

Overload Protection Provided

Automated Working process from Tube Loading to Finished Products Output

Automatic Orientation Effected by Photoelectric Induction

Chiller

Date Coding Embossing

Material level control system

Optional Devices

Change Parts For Different diameter tubes

Pneumatic plunger type material feeding pump

Heating and warm keeping function for hopper

Mixing function for hopper

Technical Parameters

Filling volume: 1-300ml/unit (Adjustable)

Filling accuracy:0.5%

Capacity:3600-4800unit/hour, Adjustable

Tube diameter: Φ12-60 mm

Tube length: 50-240 mm

Hopper volume: 40L

Power: 380/220V 50/60HZ, 3Phase

Air pressure: 0.4-0.6 MPa

Equipped motor: 1.1KW

Machine power: 5kw

Inner wind motor: 0.37kw

Convulsions motor: 0.37kw

Dimension: 2270×960×2100(mm)

Weight: About 1350 Kg
