V Type High Effective Powder Mixing Machine With No Dead Corner By Stainless Steel

V Type High Effective Powder Mixing Machine With No Dead Corner By Stainless Steel

    • V Type High Effective Powder Mixing Machine With No Dead Corner By Stainless Steel
    • V Type High Effective Powder Mixing Machine With No Dead Corner By Stainless Steel
    • V Type High Effective Powder Mixing Machine With No Dead Corner By Stainless Steel
  • V Type High Effective Powder Mixing Machine With No Dead Corner By Stainless Steel

    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE, GMP
    Model Number: VH

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiation
    Packaging Details: Export standard wooden case
    Delivery Time: 25days
    Payment Terms: L/C, T/T
    Supply Ability: 25sets/month
    Contact Now
    Detailed Product Description

    V Type High Effective Powder Mixing Machine With No Dead Corner By Stainless Steel





    Quick Detail:



    Model Name: VH

    Capacity: 72-2400kg/batch

    Material Fed in Time: 3-25min

    Mixing Time: 4-12min

    Motor Power: 1.1Kw-18.5kw

    Rotating Height: 1580mm-5300mm

    Total Weight: 280kgs-3850kgs





    Description:





    1. It is used to mix the dry-powder, granular materials with good liquidity.

    2. It consists of two asymmetric cylinders. The materials can flow as vertical and horizontal direction. The       mixing uniformity will be above 99%.

    3. It adopts vacuum feeding under sealing state. There’s no driving structure inside and be clean, no             dead corner in according with GMP standard.





    Applications:





    The mixer is used for mixing the dry material grains in the medical, chemical, food, metallurgical and other industries.





    Specifications:





    Type Whole volume (M3) loading factors Max. loading capacity A B C D E F

    L

    (mm)

    W

    (mm)

    Center height

    (mm)

    Feeding hole diameter(mm) Diameter of discharge hole (mm) Height of discharging hole (mm)
    VH-0.1 0.1 0.4 40 1900 600 1190 ф250 ф80 650
    VH-20L 0.02 0.4 20 1600 500 1230 Ф210 Ф50 610
    VH-100 0.2 0.4 80 2270 700 1440 ф300 ф100 750
    VH-0.3 0.3 0.4 120 2320 800 1470 ф300 ф100 750
    VH-200 0.5 0.4 200 2520 900 1510 ф300 ф150 750
    VH-1.0 1.0 0.4 400 3040 1000 1765 ф400 ф150 750
    VH-1.5 1.5 0.4 600 3300 1000 1750 ф400 ф200 750
    VH-2.0 2.0 0.4 800 3700 1200 2000 ф400 ф200 750
    VH-2.5 2.5 0.4 1000 3950 1500 2200 ф400 ф200 750
    VH-3.0 3.0 0.4 1200 4100 1500 2140 ф400 ф200 750







    Competitive Advantage:



    1. we have seven technicians who gets passport ready to travel all over world to offer service to you.

    2. We have 24hours hot line for Technical Support.

    3. We get 18hours internet line for technical support.

    4. Video camera in workshop to help you adjust and solve machine problem in working situation.

    5. We have Technical Support in below Foreign Cities:

    California (commission worker), Manila and Davao (Distributor), Lima (Agent), Ho Chi Ming and Hanoi (Agent), Dhaka (Agent), Laho
