Hot Air Circulating Pharmaceutical Dryers Herbal Medicine Oven Low Noise

Brand Name:	LTPM China
Model Number:	CTC Series
MOQ:	1set
Payment Terms:	L/C, T/T
Supply Ability:	25sets/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, GMP

Drying Quantity Per Time (kg):

25-200

Power Of Blower Fan (kw):

0.45-1.1

Consumed Steam(L/min):

5-40

Drying Cart (pcs):

0-2

Drying Pan(pcs):

24-96

Machine Size (mm):

1550-2300*1000-2200*2044-2433

Upper And Lower Temp. Difference:

±2

Service Temperature:

Electrical Heating 50-350℃

Packaging Details:

Export standard wooden case

Supply Ability:

25sets/month

Highlight:

Herbal Medicine Pharmaceutical Oven

low noise Pharmaceutical Dryers

Hot Air Circulating Pharmaceutical Dryers

Product Description

CT-C series hot ar circullation drying oven uses a ow noise and high temperature proof axial flow blower and an automatic temperature control system. The whole circulation system Is the tully enclosed to make that the heat efficiency of the drying oven increases from 3.7% of the traditional drying oven to 35-45% of the present one. The highest heat efficiency can reach 50% .
The successtul design of CT-C hot air circulation drying oven makes that the hot air circulation drying oven in our country catch the advanced level both at home and abroad. In order to save a large quantity o the energy in out country, in order to enhance the economic results of the enterprises.

Hot Air Circulating Pharmaceutical Dryers Herbal Medicine Oven Low Noise 0

Product Features
1. Most of the hot air circulates in the tank with high thermal efficiency and energy saving.
2. Using the forced ventilation, adjustable air plate is set in the box, and the material is dried evenly.
3. Wide selection of heat source, such as steam, hot water, electricity, far-infrared.
4. Low noise, balanced operation, automatic temperature control, convenient installation and maintenance.
5. Wide range of applications, drying series of other driers have their specific uses, such as dehydrated vegetables drying machine suitable for dehydration vegetables drying, Chinese medicine spray drying machine for drying Chinese medicine, and hot air drying oven can dry all kinds of materials, is a general drying equipment.

Technical Data

Model & spec.	Drying quantity per time (kg)	Power of blower fan (kw)	Consumed steam(L/min)	Drying cart (pcs)	Drying pan(pcs)	Machine Size (mm)	Upper and lower temp. difference
CTC-0	25	0.45	5	0	24	155010002044	±2
CTC-1	100	1.1	20	2	48	230012002433	±2
CTC-2	200	1.1	40	2	96	230022002433	±2

Applications
This drying oven is suitable for the material and product hot solidificationand dry de-watering in the pharmaceutical, chemical, food, farming, side-product, aquatic product, light industries, heavy industries andothers industries. Such as raw material medicine, crude drug, preparedherbal medicine of Chinese traditional medicine, plaster, powdparticle, drinking agent, pill, packing bottle, pigment, dyestuff, de -watering vegetable, dried fruit piece, sausage, plastics, resin, electric component, baking varnish and etc.

Hot Air Circulating Pharmaceutical Dryers Herbal Medicine Oven Low Noise 1
