Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers

Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers

Hot Air Heat Pump Circulation Tray Dryers

Dewatering Hemp Hot Air Circulation Dryers

Dewatering Hemp Dried Leaves Flowers Dryer

Place of Origin:

China

Brand Name:

LTPM China

Certification:

CE, GMP

Model Number:

CTC Series

Contact Us

Request A Quote
Product Details
Drying Quantity Per Time (kg):
25-200
Power Of Blower Fan (kw):
0.45-1.1
Consumed Steam(L/min):
5-40
Drying Cart (pcs):
0-2
Drying Pan(pcs):
24-96
Machine Size (mm):
1550-2300*1000-2200*2044-2433
Upper And Lower Temp. Difference:
±2
Service Temperature:
Electrical Heating 50-350℃
Product Description

The high-temperature heat pump drying unit uses the reverse Carnot principle to absorb heat from the surrounding environment and transfer it to the object to be heated (the object with a higher temperature). Its working principle is opposite to the principle of the refrigerator, which is based on the reverse Carnot principle. The principle of circulation works, the former increases the temperature and the latter decreases the temperature.

Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers 0Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers 1

1. Firstly, the dry evaporator of the refrigerant absorbs air from the outside.
2. Then, the compressor starts to work to increase the air temperature.
3. Next, the heat exchanger converts the hot air into a drying chamber.
4. Finally, the material will be dried by the hot air circulating in the drying chamber.

Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers 2Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers 3

Technical Data

Model & spec. Drying quantity per time (kg) Power of blower fan (kw) Consumed steam(L/min) Drying cart (pcs) Drying pan(pcs) Machine Size (mm) Upper and lower temp. difference
CTC-0 25 0.45 5 0 24 1550*1000*2044 ±2
CTC-1 100 1.1 20 2 48 2300*1200*2433 ±2
CTC-2 200 1.1 40 2 96 2300*2200*2433 ±2



Packaging Details:

Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers 4



Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers 5

Hot Air Heat Pump Circulation Tray Dryers Dewatering Hemp Dried Leaves Flowers 6
