Home ProductsPharmaceutical Dryers

Belt Type Vacuum Drying Machine Pharmaceutical Dryers With 2 Years Warranty

Belt Type Vacuum Drying Machine Pharmaceutical Dryers With 2 Years Warranty

    • Belt Type Vacuum Drying Machine Pharmaceutical Dryers With 2 Years Warranty
    • Belt Type Vacuum Drying Machine Pharmaceutical Dryers With 2 Years Warranty
    • Belt Type Vacuum Drying Machine Pharmaceutical Dryers With 2 Years Warranty
  • Belt Type Vacuum Drying Machine Pharmaceutical Dryers With 2 Years Warranty

    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE
    Model Number: Vb-Top Series

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiation
    Packaging Details: Wooden Case
    Delivery Time: In 30 days after receiving the deposit
    Payment Terms: 30% TT as deposit and 70% before shipping
    Supply Ability: 25 sets/Month
    Contact Now
    Detailed Product Description
    Outline Dimension Diameter * L * H Mm: Φ3000*18000*4600 10layer Heating / Cooling Area M^3: 200/14
    Evaporation Capacity Kg / H: 190-210 Power KW: 55
    Vacuum Degree Pa: 1600-5000  Heating / Cooling Temp ℃: 15-30 (adjustable)



    VB-Top-Series Vacuum Belt Dryer

    Working Principle:

    VBD can accomplish continuous feeding and discharging of material in vacuum state, turn the traditional static drying to dynamic vacuum drying, reduce traditional drying time from 10-20 hours to 30-60 minutes, reach the goal of adjusting drying temperature according to different materials, and solve the problems difficult for spray dryer, and also solve the problem of denaturalization of material due to the long time drying by traditional oven. VBD can create the drying process which traditional dyers can not fulfill. The color, solubility and the preservation of the active ingredient of the dried product by VBD is unrivaled.

    Advantages:

    Short drying time (adjustable between 20-90 minutes)
    Minimum loss of aroma
    Little loss of product
    No Oxidation of product
    No Mechanical stress
    Solvent recycling possible
    Low product temperatures (adjustable between 20°C-150°C)
    Less energy consumption
    Completely closed system
    No pollution of environment
    Controllable maillard reaction
    Instant properties of the drier products
    PLC Automatic control system
    CIP Cleaning system
    GMP Standards


    Main Technical Data:

    Model

    Outline dimension Diameter * L * H
    mm

    Heating / cooling area m^3

    Evaporation
    capacity
    Kg / h

    Power KW

    Vacuum degree
    Pa

    Heating / cooling temp ℃
    VB-TOP-6Φ1000*6000*2600 2layer5/0.364-612




    1000-3300




    40-135 (adjustable)

    VB-TOP-8Φ1000*7500*2600 2layer6.5/0.55-812
    VB-TOP-12Φ1200*7500*2700 3layer11/1.87-1213
    VB-TOP-15Φ1600*7500*2800 3layer14/1.89-1513
    VB-TOP-25Φ1600*9000*2800 3layer25/1.818-2515
    VB-TOP-30Φ1800*9000*2900 4layer29/228-3218
    VB-TOP-50Φ1800*12000*2900 4layer46/2.435-5020
    VB-TOP-60Φ1900*12000*3200 5layer57/350-6024
    VB-TOP-80Φ2300*12000*3400 6ayer75/3.670-8028




    1600-5000




    15-30 (adjustable)

    VB-TOP-100Φ2300*15000*3600 6layer94/3.690-10034
    VB-TOP-130Φ2600*15000*3800 7layer118/5110-13040
    VB-TOP-150Φ2800*16500*4200 8layer147/6.8140-15046
    VB-TOP-180Φ3000*16500*4500 9layer178/7.6160-18050
    VB-TOP-210Φ3000*18000*4600 10layer200/14190-21055


    Different Drying Machine Comparison:

    ItemVacuum Belt DryerFreeze DryerVacuum OvenSpray Dryer
    Drying temperatureLow /MediumLowMedium/HighHigh
    Drying time30-60minutes20-35hours10-20hoursshort
    Production solubilityGoodGoodOrdinarycOrdinaryc
    Product qualityGoodGoodOrdinarycOrdinaryc
    Property reservationGoodGoodOrdinarycOrdinaryc
    Operation costLowHighMediumHigh
    Equipment investmentMediumHighLowLow
    Application scopeWideOrdinaryWideLow
    Continuous productionYesNoNoYes




    Purchasing Process:
    step1: Please fill our enquiry list for you.
    step2: Suitable drying equipment will be recommended according to your requirements.
    Step3: Free test for your offered materials is suggested (We have a free experiment platform for our customers)
    Step4: Dried products are sent back for you to test relevant indexes.
    Step5: Right type machine will be chosen for you according to your producing capacity.
    Step6: Competitive price and equipment drawing will be offered to you.
