304 Stainless Steel Automatic Rotary Powder Filling Machinery Custom Made
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | GD8-200B |
| Certification: | CE |
| Model Number: | GD8-200B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25 |
|---|---|
| Price: | 1000USD |
| Packaging Details: | Wooden Case |
| Delivery Time: | 25 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 25 |
|
Detail Information |
|||
| Type:: | Packing Machine | Application: | Food,daily Chemical Etc |
|---|---|---|---|
| Automatic Grade:: | Automatic | Dimension(L*W*H):: | 2000*1200*2400MM |
| Additional Function: | Hanging Hole,special Shape | Bag Shape:: | Zipper Bag/doypack |
| High Light: | automatic packaging machine,packing machine for food products |
||
Product Description
304 Stainless Steel Automatic Rotary Powder Filling Machinery Custom Made
304 Stainless Steel Automatic Rotary Powder Filling Machinery Custom Made
Performance
The automatic rotary bagging machine, fast-acting and reliable, is ideal for flexible bag styles and ranges as well as offers quick changeovers. With different metering and filling equipment, it is suitable for a variety of industries and products (Granules, Powder, Liquids and Pastes or other nature).
Features :
- SIEMENS PLC & Colorful Touch-Screen controlled fully automatic machine
- Frequency Conversion Speed Adjuster and SMC Cylinder Driven
- Widely flexible pouch formats and product types
- Self-diagnostic function-no filling, no heating, nor sealing if the bags not open or not open completely
- Auto-brake for self-protection when machine stops
- Customized zipper auto-open construction to avoid pouch broken nor deformed
- Applicable bags material-Laminated film, monolayer PE, PP and paper
Technical parameters :
|
Equipment model |
GD8-200B |
|
Equipment material |
304 stainless steel |
|
Pneumatic component |
SMC,AirTAC |
|
Vacuum component |
Vacuum generator (SMC) |
|
Drive mode |
Frequency conversion motor drive |
|
Measuring type |
Auger filler, linear weigher |
|
Operation interface |
Touch screen(double language:Chinese and English) |
|
Bag materials |
Heat sealable film as PA/PE,PET/PE,AL film etc. |
|
Bag size |
W:70~200mm L:100~300mm (date coding requires≥140mm length) |
|
|
|
|
Filling range |
5~1500g |
|
Packing speed |
20~45bags/min (depended on the product and filling weight) |
|
Package accuracy |
Error≤±1% |
|
Weight |
RZ6-200:800kg |
|
|
RZ8-200:1000KG |
|
Dimension |
RZ6-200:1475*1325*1480(L,W,H) |
|
|
RZ8-200:1635*1455*1480(L,W,H) |
|
Total power |
RZ6-200:1.5kw |
|
|
RZ8-200:2.3kw |
|
Driving power source |
380V Three-phase Five-line 50HZ |
|
Control power source |
DC24V |
|
Compress air requirement |
≥0.45m³/min (compress air is provided by user) |
