Environmental Shrink Film Automated Packaging Machine With Touch Screen

Environmental Shrink Film Automated Packaging Machine With Touch Screen

Product Details:

Place of Origin: China
Brand Name: LTPM China
Certification: CE, GMP
Model Number: BM

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 25days
Payment Terms: L/C, T/T
Supply Ability: 25sets/month
Get Best Price Contact Now

Detail Information

High Light:

automated packaging equipment

,

packing machine for food products

Product Description



Environmental Protection Shrink Film Automatic Packaging Machine With Touch Screen Operation





Quick Detail:





Produce the Ability: 20-30package/min

Contract the Speed: 0-10m/min

Max Packing Size: 500×320×125mm W+H<400mm

Thickness×Width: 0.012~0.05×200~550mm Roll material diameter 300mm

Packing Material: PO,POF three layer co extrusion environmental protection shrink film

Air Pressure: 0.5Mpa

Power Supply: 220V 60Hz

Overall Dimensions: 3700×850×1400mm

Weight: 600Kg





Description:





Automatic Film Shrinking Packing machine adopts Germany Siemens PLC and temperature control module and touch screen operation, accurate and intuitive. Traction by a stepping motor is running, remove bag-making error. Shrink tunnels dual-blower operation, airflow cross-rotation to reach the furnace temperature uniformity. Frame stainless steel frame, easy maintenance, cleaning.





Applications:





This machine is widely used in beverage, food and chemical packaging industries. it does not need the wooden cases, and bottles can be packed in square, round and flat shape.





Specifications:





Packing Material PO,POF three layer co extrusion environmental protection shrink film
Thickness×Width 0.012~0.05×200~550mm Roll material diameter 300mm
Max Packing Size 500×320×125mm W+H<400mm
Contract the Speed 0-10m/min
Produce the Ability 20-30package/min
Air Pressure 0.5Mpa
Power Supply 220V 60Hz
Power 8.5Kw
Overall Dimensions 3700×850×1400mm
Weight 600Kg
Main Material 304 Stainless steel





Competitive Advantage:





1. we have seven technicians who gets passport ready to travel all over world to offer service to you.

2. We have 24hours hot line for Technical Support.

3. We get 18hours internet line for technical support.

4. Video camera in workshop to help you adjust and solve machine problem in working situation.

5. We have Technical Support in below Foreign Cities:

California (commission worker), Manila and Davao (Distributor), Lima (Agent), Ho Chi Ming and Hanoi (Agent), Dhaka (Agent), Laho
