Automatic Electronic Tablet Counting Machine with Multi Channel Omron System
|Place of Origin:||China|
|Brand Name:||LTPM China|
|Certification:||CE, GMP, SGS, BV|
Payment & Shipping Terms:
|Minimum Order Quantity:||1set|
|Packaging Details:||Export Standard Wooden Case|
automatic tablet counting machine,
pill counting machine
LTEC-12 Multi channel Counting machine with vibrating function
Passed CE Certification up to GMP Standard
Newly Developed Software Controlling System suitable for different batch of production
It needs no changing parts while switch product size.
LTEC-12 Automatic Electronic counting machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc. This machine adopts 12 sets imported counting sensor for counting with 12 Guiding Way and two head. The advantage of the machine is no need change mould when you change the counting object, only adjusting the counting table height by Easy Adjust wheel. The machine comes with Touch screen operation and PLC Control for convenient running.
wide application and use of the Company's original anti-dust photoelectric detection of high technology, can count Tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pill count to bottling;
Soft Gelatin capsule
other solid object under machine range
|Filling Quantity||10-9999pcs/bottle (adjustable)|
|Conveyor Belt Length||2400mm|
|Machine Size L × W × H (mm)||1450 × 1100 × 1400|
- Compatibility, high accuracy, wide application and use of the Company's original anti-dust photoelectric detection of high technology, can count Tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pill count to bottling;
- Vibratory cutting drugs do not damage;
- A high degree of intelligence, with no bottle is not the number of self-fault detection alarm and many other control functions;
- Compact structure, stability and durability, and no regular replacement parts, small footprint, the use of low-cost;
- To facilitate the replacement of species, can automatically take-off and landing, demolition cleared without any tools, convenient and quick;
- Chinese dialogue control panel, can store 10 ~ 20 group of species parameters, adjusted to facilitate the use of special;
- Fully automatic operation, with the Upper and Lower Union Road, intelligent control of processes, coordination, and no special operation, labor-saving devices.
- Low prices, especially for small-volume, variety and more manufacturers use.
- Control chip imported to the United States, photoelectric sensors for Taiwan's imports.
