Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type

Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type

Product Details:

Place of Origin: Zhejiang Province,China
Brand Name: LTPM CHINA
Certification: CE, GMP, SGS, BV
Model Number: DXD-Series

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export Standard Wooden Case
Delivery Time: 25 days
Payment Terms: L/C, D/A, D/P, T/T, MoneyGram
Supply Ability: 45 sets/month
Get Best Price Contact Now

Detail Information

Machine: Pillow Packaging Machine Max.Film Width: 260mm
Max Capacity Of Packing: 20-120 Pcs/ Min Film Thickness: Film Thickness
Bag Length: 60-300 ( Do Not Exceed This Size ) Packing Width: 25-150mm
High Light:

Tea Bag Packaging Machine 80ml

,

150mm Width Tea Bag Packaging Machine

,

Pneumatic Type Automated Packaging Machine

Product Description

Automatic 150mm Width Tea Bag Packaging Machine



This machine is applicable to single items packing or/and mixed 2-3 types of items packing, operating easily with PLC control system. Firm sealing, smooth and elegant bag shape, high efficiency and durability are preferred elements. Automatic ordering, counting, packing and printing can be offered. Equipped with exhaust device, printer, labeling machine, transfer conveyor and weight checker make it better.



l Adjustable dwell time for better looking seals and increased packaging speeds
l Film auto tracking, Length registered by photo sensor or Encoder
l Heavy-duty jaw assembly houses a cushion for shock and noise abatement
l 3 Independent temperature control
l Rugged, durable equipment to withstand severe environment
l Security guards with security sensors
l Coding kit (date)





Packaging Materail: Laminated heat-sealing plastic film.Like OPP/CPP,OPP/CE, PET/PE ETC.

Bag type: Pillow back sealing,3/4 sides sealing, hole punch, bag linking, easy tear etc.

Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type 0

Product Features:

1. The Pneumatic pump packaging machine can automatically complete the products of fasteners conveying, measuring, filling, bag making, date printing, heat sealing and cutting etc.
2. Stepper motor driving system is adopted in the packaging machine.
3. To ensure the same lengthe of each bag, high sensitive electro-optical sensor system is provide to the realize automatic a lignment on the packing film.
4. The packaing machine is equuipped with a computer control system.
5. We have installed constant temperture heating system ensuring stable temperture and keep temperature is +/-1°c.
6. The electroic and pneumatic components of the machine are all supplied by reliable supplier copperating with us for several years, which can ensure the quality of machine and save the cost of purchese meantime.
7. The bag size and packaging number can be customized by customers.



Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type 1

Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type 2



Technical Parameters

Items / Model
DXD-350K
DXD-500K
DXD-900K
Pouch length
50-250mm(L) (adjustable)
50~160mm
50~120mm( Pouch length can change)
Pouch width
50-85mm(W)
50~105mm
50~105mm
Packing speed
30-50times/min depend on pouch size and material
20~50times/nim(depend on pouch size and material)
80times/nim(depend on pouch size & material)
Measuring range
1-50ml
1~80ml
1~80ml
Applicable film
PET/AL/PE PET/PE NY/AL/PE NY/PE
PET/AL/PE PET/PE NY/AL/PE NY/PE
PET/AL/PE PET/PE NY/AL/PE NY/PE
Max width of film roll
350mm
500mm
900mm
Max film roll diameter
300mm
420mm
Φ300mm
Film roll core diameter
75mm
75mm
Φ75mm
Power voltage
220V/ 50HZ(do as customer’s request)



380V50Hz 3P 4W
380V 50Hz (do as customer's request)
Power
5.5kw
12 Kw
12 Kw
Gross Weight
650kg
1200kg
1200kg
Package size
(L)1400mm×(W)1000mm×(H)1700mm
1680x1280x2050mm
1500x1540x2200mm(L x W x H)

Machine Details

Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type 3Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type 4Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type 5



Application:

Suitable for liquid juice, ice lollipop, ice tubes, oil, paste, sesame oil, ketchup, tomato sauces and so on.

Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type 6

Automatic 150mm Width Tea Bag Packaging Machine 80ml Pneumatic Type 7
