Place of Origin:
CHINA
Brand Name:
LTPM CHINA
Certification:
CE
Model Number:
DPP-Series
Contact Us
1.Using photoelectric control system, PVC, PTP, rigid aluminum packaging automatic feeding, waste edge automatic punching device to ensure the long-distance multi-station synchronization stability;
2. Can be equipped with additional photoelectric detection and correction device, imported stepper motor traction, graphic and text printing and packaging to optimize the packaging grade;
3. This machine is suitable for: blister-sealed packaging of capsules, plain tablets, sugar-coated tablets, gel pills, injections, special shapes, etc., as well as medical equipment, light food, and electronic components.
| Punching Frequency | 10-40time/min |
| Production Capacity | 2400 pcs/h |
| Max formed area and depth | 80*110*26mm |
| Standard stroke range | 20-70mm, can as customer request |
| Standard section | 80*57mm, can as customer request |
| Air pressure | 0.6-0.8MPa |
| Total power | 220/380V 50Hz 3.2KW |
| Main electrode power | 0.75kw |
| PVC rigid sheet | 0.15-0.5*80mm |
| PTP aluminum foil | 0.02-0.035*80mm |
| Dialysis paper | 50-100g*80mm |
| Mould cooling | Tap or circulation water |
| Noise index | less than 75dBA |
| Dimension | 1600*650*1100mm |
| Weight | 550kg |
