Place of Origin:
CHINA
Brand Name:
LTPM CHINA
Certification:
CE
Model Number:
DPP-Series
Contact Us
1. Use domestic high-power transmission mechanism is adopted, and the main rotating shaft is driven by the chain, eliminating the errors and noise of other gear transmissions;
2. The appliance adopts an imported control system, which can be configured with missing material missing and missing device and missing particle detection and removal device according to customer requirements;
3. The whole machine adopts segmented combination: PVC forming, feeding, heat sealing is one segment, and tropical aluminum cold forming, heat sealing, and punching are divided into one segment for split packaging;
Model | DPP140 |
Punching Frequency | 10-40time/min |
Production Capacity | 2400 pcs/h |
Max formed area and depth | 80*110*26mm |
Standard stroke range | 20-70mm, can as customer request |
Standard section | 80*57mm, can as customer request |
Air pressure | 0.6-0.8MPa |
Total power | 220/380V 50Hz 3.2KW |
Main electrode power | 0.75kw |
PVC rigid sheet | 0.15-0.5*80mm |
PTP aluminum foil | 0.02-0.035*80mm |
Dialysis paper | 50-100g*80mm |
Mould cooling | Tap or circulation water |
Noise index | less than 75dBA |
Dimension | 1600*600*1100mm |
Weight | 450kg |
