Place of Origin:
CHINA
Brand Name:
LTPM CHINA
Certification:
CE
Model Number:
DPP-Series
Contact Us
Features
1. It adopts the newest type high-power transmission mechanism to arrange the chain and drive the main driving shaft. The errors and noises of other gear wheel transmission can be avoided.
2. Imported controlling system is adopted; also it can be equipped with detecting and rejection function device for number of medicines according to the user's requirement.
3. It adopts photoelectrical controlling system to make PVC, PTP, Aluminum/Aluminum material to be automatically fed and waste side to be cut automatically to guarantee the Synchronous stability of over- length distance and multi stations.
4. It can be optional equipped with photocell correction device, imported stepper motor traction and image- character register to optimize packing grade.
| Punch frequency | 10-20times/min |
| Production capacity | 2400plates/hour |
| Max.Forming area & Depth | 105*70(standard depth ≤15mm),Max.depth 25mm |
| Standard stroke range | 30-80mm (can be designed) |
| Standard plate size | 80*70mm (can be designed) |
| Air pressure | 0.4-0.6Mpa |
| Compressed air required | Air compressor ≥0.3m3 /min |
| Total power supply | 220v 50hz 2.8kw |
| Main motor | 0.75kw |
| PVC hard film | 0.15-0.5*110mm |
| PTP Aluminum Film | 0.02-0.035*110mm |
| Dialysis Paper | 50*100g*110mm |
| Mould cooling | Tap water or recycling water |
| Overall dimension | 1840*900*1300 (mm) |
| Weight |
Net weight:480kg Gross weight:550kg |
| Noise index | < 75dBA |
