Place of Origin:
CHINA
Brand Name:
LTPM CHINA
Certification:
CE
Model Number:
DPP-Series
Contact Us
Main Technical Parameters
| Cutting Frequency (Times/min) | 27 |
| Capacity (10 thousand pcs/h) | 1.1-6.5 |
| Stroke (mm) | 40-110 |
| Max. Forming Area and Depth(mm) | 60×100×14 |
| Air Compressor(m³/min) | ≥0.3 (provided by user) oilless air compressor better |
| Air Pressure (Mpa) | 0.4 |
| Standard Plate(mm) | 80×57 can be manufactured as user's requirements |
| Total Power | 380V/220V 50Hz 2.8kw |
| PVC Hard Pieces(mm) | 0.25-0.35×90 |
| PTP Aluminum Foil(mm) | 0.02-0.035×90 |
| Mould Cooling | tap water or recycling water |
| Overall Dimensions(mm) | 1300×400×1070(L×W×H) |
| Weight(kg) | 450 |
Applications:
1.The key electric appliance of his machine adapts PLC processor, temperature modular, touch screen to operate, high quality product, can be equipped with cursor device etc. as customer`s requirement.
2.Machine-tool track type of casting machine-base, taken these processing like backfire, maturing, high benchmark and without distortion.
3.Each box of section processed through professional equipment, to assure high precision and good ex-changeability.
4.Forming, sealing, slitting etc. parts are all could be adjust freely on the track with triangle string and flat string, strong applicability. small oversize, save installation space.
5.Reducer adapts parallel-axes bevel wheel, to avoid loose and smooth between chain or strap when it is driving.
6.Stroke can be adjust freely, widely used, ease of operation, stable running.
7.It adapts up and down net pattern concave-convex to conjugate, multi-step air cylinder, double-heat sealing. Quality sealing.
