Rotary High Speed Automatic Round Bottle Labeling Machine 300-600 Bottles / min

Rotary High Speed Automatic Round Bottle Labeling Machine 300-600 Bottles / min

Product Details:

Place of Origin: China
Brand Name: LTPM China
Certification: CE, GMP
Model Number: MT

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 25days
Payment Terms: L/C, T/T
Supply Ability: 25sets/month
Get Best Price Contact Now

Detail Information

High Light:

bottle labeler machine

,

self adhesive labelling machine

Product Description

Rotary High Speed Automatic Round Bottle Labeling Machine 300-600 Bottles / min


Rotary High Speed Automatic Round Bottle Labeling Machine 300-600 Bottles / min​


Quick Detail:


The application specification of label graze paper: Opaque label
Running speed: 300-600bottles/min
Material: Stainless steel 304
Labeling accuracy: ±1mm
Model No.: MT-600
Driving mode: Servo motor
Overall Size: 2780×1270×1500mm
Weight:300kg
Certificate: CE Certificate


Description:


1. Before and after the optional section of pipeline to connect, or close match is expected turntable for product collection, sorting and packaging
2. Machine-wide adoption of a mature technology SIEMENS PLC control system, so that the whole stable, high-speed.
3. Operating system using touch-screen control, simple, practical, efficient.
4. Rotary structure, Ultra-high speed and stable operation.
5. Code machine the art technology, print the writing clear, fast and stable.
6. The scope of application can be used for a variety of sizes of round bottle labeling.
7. Roll-bottle attached to lose, so that the labels attached to a more solid.

Applications:


MT-600 Rotary Ultra-high Speed Automatic Labeling Machine, in order to achieve rationalization of production target and design. The machine comes with automatic labeling process, simple operation, high speed running, accurate labeling position, beautiful labeling. The machine can be used for pharmaceutical, chemical and foodstuff Industry labeling.


Specifications:


Production300-600 bottles/min
Labeling speed≤40m/min
Labeling accuracy±1mm
The application specification of label graze paperOpaque label
The application of bottleOuter diameter 10-24mm Height 25-95mm
The application of labelWidth 20-70mm Length 25-80mm
The inner diameter of label volume76mm
The outer diameter of label volumeMax. 350mm
Driving modeServo motor
The power of motor1000w
Size appearance2780×1270×1500mm
Weight300kg
VoltageAC 220V 50/60Hz Single phase (according to the voltage in client country)
Labeling methodsThe bottle is stand into, stand paste, stand out



Competitive Advantage:


1. We have seven technicians who gets passport ready to travel all over world to offer service to you.
2. We have 24hours hot line for Technical Support.
3. We get 18hours internet line for technical support.
4. Video camera in workshop to help you adjust and solve machine problem in working situation.
5. We have Technical Support in below Foreign Cities:
California (commission worker), Manila and Davao (Distributor), Lima (Agent), Ho Chi Ming and Hanoi (Agent), Dhaka (Agent), Laho
