Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper

Product Details:

Place of Origin: CHINA
Brand Name: LTPM CHINA
Certification: CE
Model Number: DPP-Series

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: wrapped with strech film packed into Export Standard Wooden case, this package afford long time sea shipment and anti moisture.
Delivery Time: 25days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 25 SETS Per month
Get Best Price Contact Now

Detail Information

Stroke (mm): 40-160 Can Be Manufactured As User’s Requirements Capacity: 45cutting/min
Packaging Type: Alu/PVC And Alu/Alu Package Control System: Micro Computer
Feeding:: Universal Feeder Power: 2.2kw
Standard Plate(mm): 80×57 Can Be Manufactured As User’s Requirements Air Pressure(Mpa): 0.4-0.6
Air Supply: ≥0.3 M³/min Mould Cooling: Tap Water Or Recycling Water
High Light:

Injection Syringe Blister Packing Machine

,

Medical Swab Blister Packing Machine

,

Tyvek Paper Blister Packing Machine

Product Description

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper

Blister Packing Machine DPP-Series is designed by our company based on the advantages of aluminum-plastic packing machines at home and abroad. The key parts of the machine adopt a number of our innovative technologies. The parts in contact with materials are made of stainless steel and high-grade aluminum alloy. This machine is suitable for pharmaceutical, food and health products industries to pack tablets, capsules, small pieces of food, even hardware parts and electronic components. The machine integrates ten functions, including coiled material uncoiling, aluminum and plastic feeding, blister forming, filling, waste material recycling, heat sealing, batch number printing, reticulate indentation, sheet blanking, finished product counting, etc. The finished products are well sealed, safe and hygienic. As the machine is improved by technology and meets GMP standard, it has been sold to major pharmaceutical factories and large and medium-sized hospitals at home and abroad, and also exported to more than 20 countries and regions, favored by customers.

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper 0

Performance Features:
● It adopts variable-frequency stepless speed regulation.
● The stroke is adjustable, ranging from 30 to 100mm. And the adjustment is easy.
● It adopts plate mold, positive pressure forming, batch number, indentation line, automatic release of aluminum foil and PVC.
● It is equipped with a universal feeder which help achieve the filling rate as high as 99.5%. The feeder can be equipped with a dust suction interface, so as to eliminate dust caused during the feeding process.
● With plate aligning heating, the heat loss of the heater is minimized and the required temperature of the heater is greatly reduced.
● Each station is equipped with four stand columns, which brings better stability and better effect of forming, heat sealing, indentation and blanking.
● It has the advantages of taking up less space, light weight, compact structure, simple operation and convenient maintenance.



Specifications:

DPP Automatic Blister Packaging Machine

DPP-80
DPP-140
DPP-250
Blanking frequency
PVC-AL: 10-40 times/min AL-AL: 10-30 times/min
PVC-AL: 10-40 times/min
AL-AL: 10-30 times/min
PVC-AL: 10-40 times/min
AL-AL: 10-30 times/min
Adjustable scope of feed travel
30-100mm(adjustable)
30-120mm(adjustable)
30-140mm(adjustable)
The max forming area and depth
120mm×90mm×20mm
150mm×120mm×26mm
240mm×130mm×26mm
Wrapper: ALU
Length: 130mm,
thickness: 0.02-0.035mm
Length: 160mm,
thickness: 0.02-0.035mm
Length: 250mm,
thickness: 0.02-0.035mm
Wrapper: PVC
Length: 130mm,
thickness: 0.25-0.5mm
Length: 160mm,
thickness: 0.25-0.5mm
Length: 250mm,
thickness: 0.25-0.5mm
Wrapper: PTP
Length: 130mm,
thickness: 0.02-0.035mm
Length: 160mm,
thickness: 0.02-0.035mm
Length: 250mm,
thickness: 0.02-0.035mm
Wrapper:Dialysis paper
Length:130mm, specification:50-100 gram
Length:160mm, specification:50-100 gram
Length:250mm, specification:50-100 gram
Power of forming heating
1.5KW
2.4KW
3KW
Power of sealing heating
1.5KW
2.4KW
3KW
Main motor power
0.75KW
1.5KW
1.5KW
Machine Voltage
380V/220V 50Hz
Capacity of air compressor
≥0.2m3/min
Pressure: 0.4~0.6MPa
≥0.2m3/min
Pressure: 0.5~0.7MPa
≥0.2m3/min
Pressure: 0.5~0.7MPa
Overall dimension
2070mm×650mm×1060mm
2350×580×1500 mm
3100×670×1650mm
Weight
560Kg
800KG
1500KG



Unit Of Work:
Automatic film coating, preheating, forming, quantitative liquid filling, sealing, cutting
Product Design:
Product design: OEM/ODM custom design the shape and size of the blister product.





Machine Details:

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper 1

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper 2

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper 3

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper 4



Application:

This machine is suitable for packaging medicines, cosmetics, food, chemical products, such as single-dose liquid syrup, olive oil/ketchup/jam/butter/chocolate/honey/perfume, lotion, cream, cosmetic oil/fertilizer, pesticides, etc. .

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper 5

Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper 6Medical Swab Injection Syringe Blister Packing Machine With Tyvek Paper 7
