OEM High Shear Mixer Granulator Wet Type Granulation Machine

OEM High Shear Mixer Granulator Wet Type Granulation Machine

High Shear Mixer Granulator

Wet Type Granulation Machine

7.5KW Granulation Machine

Place of Origin:

China

Brand Name:

LTPM China

Model Number:

GHL

Contact Us

Request A Quote
Product Details
Certification:
GMP,CE,ISO,TUV
Voltage:
380V
Weight (KG):
2200
Feature:
High Working Efficiency
Dimension(L*W*H):
2635*2600*3050mm
Power (kW):
7.5
Type:
Wet Granulate Making Equipments
Function:
Granlulating
Product Description

OEM High Shear Mixer Granulator Wet Type Granulation Machine



1. It is provided with special mixing barrel and conical column of a compound structure. The corners on the inner wall are subject to smooth transition and mirror polishing with easy cleaning and without material sticking.

2. The mixing and granulating procedure can be completed in one step with the materials in the closed mixing barrel.

3. It adopts PLC control. The mixing and granulating motors are subject to variable frequency speed adjustment. All operations can be carried out automatically or manually.

4. It is provided with interlocking protection device to ensure safer operation.

5. It is equipped with printer to automatically print all process parameters, with the original records conforming to the actual ones.

6. It can be equipped with wet granulation machine and swing granulator and connect with fluidized bed dryer to form a fully closed granulating production line.

OEM High Shear Mixer Granulator Wet Type Granulation Machine 0

Specifications



Item Specification
Name Unit 10 50 150 200 250 300 400 600 800
Volume L 10 50 150 200 250 300 400 600 800
Output Kg/ batch 3 15 50 80 100 130 180 280 350
Mixing speed rpm 300/600 260/400 240/360 180/270 180/270 140/220 106/155 80/120 80/120
Mixing power Kw 1.5/2.2 4/5.5 6.5/8 9/11 9/11 13/16 18.5/22 22/30 26/34
Cutting speed rpm

1500/

3000

1500/

3000

1500/

3000

1500/

3000

1500/

3000

1500/

3000

1500/

3000

1500/

3000

1500/

3000

Cutting speed kw 0.85/1.1 1.3/1.8 2.4/3 4.5/5.5 4.5/5.5 4.5/5.5 6.5/8 9/11 9/11







Our Product

OEM High Shear Mixer Granulator Wet Type Granulation Machine 1OEM High Shear Mixer Granulator Wet Type Granulation Machine 2



LTPM CHINA provides integrated engineering solution for worldwide pharmaceutical and medical factory include the clean room, auto-control and monitoring system, pharmaceutical water treatment system, solution preparing and conveying system, filling and packing system, automatic logistics system, quality control system and central laboratory and etc. According to the pharmaceutical industry's regulatory requirements of different countries and customer's individual demand, LTPM CHINA carefully customizes engineering solutions of turnkey projects and helps customers to win the target markets, IVEN creates value to customers.


Turnkey Project for Solution Plant from A to Z


• Project Design
• Pharmaceutical Water Treatment
• Solution Preparation
• IV Solution Production Line
• Sterilization
• Inspections Packing
• Clean Room & HVAC
• Stability Chamber
• Laboratory Instruments
• Utilities
• Documentation & Qualification
• Installation, Commissioning, Training
• Service
