Homogeneous Vacuum Emulsifying Machine Hydraulic Lifting Cosmetic Cream Mixer

Homogeneous Vacuum Emulsifying Machine Hydraulic Lifting Cosmetic Cream Mixer

Product Details:

Place of Origin: China
Brand Name: LTPM CHINA
Certification: CE,SGS
Model Number: LTRZ-Series

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Packaging Details: Export Standard Wooden Case
Delivery Time: 25days
Payment Terms: T/T, L/C, D/P, Cash, Credit Card, Paypal
Supply Ability: 25sets/month
Get Best Price Contact Now

Detail Information

Mixer Type: Homogenizer Application: Viscous Fluid, Medicine Processing, Chemicals Processing
Voltage: 380V 50HZ Contact Part Material: SUS316
Using Life: More Than 15 Years Pot Working Pressure: -0.090 Mpa
Jacket Working Pressure: 0.2Mpa Spare Parts: One Year Spare Parts And Tools
High Light:

Homogeneous Vacuum Emulsifying Machine

,

Hydraulic Lifting Cosmetic Cream Mixer

,

Medicine Vacuum Emulsifying Homogenizer

Product Description

Cosmetic Machine Production Line Cosmetic Cream Mixer Vacuum Homogeneous Emulsifying Machine



This machine vacuum emulsifying homogenizer and mixer for cosmetic is widely used in Food, Chemical, Medical, Cosmetics, Agrochemical industry, applicable for filling liquid, especially for high viscosity material and foamy liquid, such as: Cream, Sauce, Wax, Hair dye, Jelly, Hair remover, Ketchup Honey, Cheese, Shampoo, Facial lotion, Lubricant oil, Ink, etc.It is the most suitable equipment to produce high-grade skin care creams and other products.





Features :
-- Vacuum system : vacuum mixing deforaming , water circulation vacuum pump, to remove the bubbles during mixing process .
-Lifting system : hydraulic lifting, convenient to clean inside homogenizer,mixer and agitator .
- Mixing type : Double direction blending and high shear homogenizer emulsifier to achieve the higher quality products .
- Movable water and oil phase : flexible manufacturing, can be used for making products separately .
- Control system: Button control ,Each function can be controlled separately. Touch screen control panel is optional.



Specifications:



Capacity Volume 200L
Kettle Cover Liquid(particle)inlet, sunk material inlet, air inlet with filter, inspect light and sight glass, vacuum port, pressure meter(1 to -0.1 bar), pressure clamp
Mixing pot Material Inner layer: SUS316L thickness: 3mm
Middle layer: SUS304 thickness: 2mm
Outside layer: SUS304 thickness:2mm
configuration Bottom material exhaust, size: 1.5”
Temp. sensor (0-199℃)
Electrical heating: 12kw, cooling water inlet
Stirring system Homogenizer

1.Material: SUS316L; standard homogenizer

2. Power: 4 kw/380/50Hz; RPM: 0--4000R/Min

Stirring scrap and middle stirring Material: SUS316L,Scrap material: PTFE

1. Stirring scrap and middle stirring use the same motor

2,Power:1.5kw/380V/50Hz;RPM:0~86r/min(Frequency control)

3. Stirring scrap and middle stirring rotating the opposite direction

Safety: 1. During stirring, the cover can not open, 2. Cover lift can not stirring.
Vacuum system

1. Vacuum pump: water recycle, power 2.35kw/380V/50Hz

2. With pressure sensor (during vacuum condition, hydraulic can not open)

Heating method Jacket electrical heating/Seam Heating
Exhaust method Electric doom and bottom discharge or positive pressure discharge material
Pressure Pressure in the pot during working: -0.090 Mpa; Jacket working pressure:0.2 Mpa
Control box SUS304 , 1.2mm thickness
Dimension 3500mm×2450mm×2250~3150 mm
Shelf is SS, platform with raised platform and SS guardrail
Spare parts One year spare parts and tools
Guarantee One year
Using life More than 15 years





Oil pot

Design volume 100L
Working capacity 90L
Stirring power 1.1kw
Stirring speed 1400 RPM
Heating power 12 Kw



Water pot

Design volume 160L
Working capacity 150L
Stirring power 1.1kw
Stirring speed 1400 RPM
Heating power 12 Kw



Homogeneous Vacuum Emulsifying Machine Hydraulic Lifting Cosmetic Cream Mixer 0

Homogeneous Vacuum Emulsifying Machine Hydraulic Lifting Cosmetic Cream Mixer 1



Machine Details

Homogeneous Vacuum Emulsifying Machine Hydraulic Lifting Cosmetic Cream Mixer 2

Homogeneous Vacuum Emulsifying Machine Hydraulic Lifting Cosmetic Cream Mixer 3Homogeneous Vacuum Emulsifying Machine Hydraulic Lifting Cosmetic Cream Mixer 4

Application

This machine belongs to a round bottle labeling machinewhich can be used for the full-cycle and half-cycle labeling of various circular bottles,and it has been widelyapplied to the round bottle products labeling of differentsizes such as round jars, round bottle, round cans incosmetics, food, medicine, daily chemical and otherlight industries.



Our Advantage
1.with many years of experience in domestic and international installation, LTPM CHINA has successivelyundertaken the integral installation of hundreds of large-sized projects.
2.Our company provides internationally top-ranking professional project installation experience andmanagement experience.
3.our after-sales service personnel have practical experience in equipment use and maintenance andreceive systemic trainings.
4.we are sincerely providing customers from home and abroad with machinery & equipment, cosmetic rawmaterials, packing materials, technical consultation and other service.

Homogeneous Vacuum Emulsifying Machine Hydraulic Lifting Cosmetic Cream Mixer 5
