Product Details:

Place of Origin: china
Brand Name: LTPM CHINA
Certification: CE
Model Number: NJP-Series

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Wooden Case
Delivery Time: In 25 days after receiving the deposit
Payment Terms: 30% TT as deposit and 70% before shipping
Supply Ability: 25 sets/Month
Get Best Price Contact Now

Detail Information

Brand: LTPM Quantity Of Mould Bores: 3pcs
Noise Standard: <80dB(A) Bores: 3
Filling Dosage: Power,pellets Dosing Precision: <±4%
High Light:

Vacuum Positioned Capsule Filling Machine

,

Integrated Capsule Filling Machine

,

3 Bores Automatic Capsule Filler

Product Description

Hot Selling NJP-Series Commercial Scale Powder Automatic Capsule Filling Machine



This model is an intermittent motion and hole plate type filling full automatic capsule filling equipment. It adopt optimization design for meeting the characteristics of Chinese medicine and the requirement of GMP, it has the characteristics of compact mechanism, small volume, lower noise, precision filling dosage, multi-function, stably running etc. It can finish the following motion at the same time: capsule feeding, capsule separating, powder filling, capsule rejecting, capsule locking, finished capsule discharge and die hole cleaning etc. It is the most ideal hard capsule filling equipment for pharmaceutical and health food industry.




Features
1. Touching-Screen, PLC program control panel with LCD.
2. Capsule vacuum positioned mechanism to make the capsule qualified over 99%.
3. Removable powder hopper for cleaning and easy auger adjustment easy to change fills weights.
4. Easy speed selection and closed capsule length adjustment.
5. Electrical Appliance control system approved to CE, and international standard.
6. Quick and accurate change part set-up, easy to remove rotary table and ring carrier assembly.
7. Fully enclosed dosing stations and rotating table for integration of the whole capsule filling plants.
8. Large cam mechanism keeps the rotating table of mould together with the whole equipment running with balance, and completely guarantees the machine operating with highest precision and accuracy.

Integrated Vacuum Positioned Capsule Filling Machine With 3 Bores 0

Technical Parameters

C Type Automatic Capsule Filling Machine
Model
NJP-400C
NJP-800C
NJP-1200C
NJP-2000C
NJP-3500C
Capacity
24000caps/h
48000caps/h
72000caps/h
120000caps/h
210000caps/h
NO.of
3
6
9
18
26
Capsule Size
000#-5# and safety capsule
Power
380/220V 50/60Hz 5kw
380/220V 50/60Hz 5kw
380/220V 50/60Hz 6kw
380/220V 50/60Hz 10kw
380/220V 50/60Hz 12kw
Dimensions
1080*1240*1950mm
1080*1240*1950mm
1180*1340*1980mm
1500*1350*2100mm
1386*1156*2100mm
Net Weight
800KG
800KG
1000KG
1600KG
2500KG
SNR
<75dB
<75dB
<75dB
<75dB
<75dB
D Type Automatic Capsule Filling Machine
Model
NJP-1200D
NJP-3000D
Capacity
72000caps/h
165000caps/h
NO.of mould bores
9
21
Capsule Size
000#-5# and safety capsule
Power
380/220V 50/60Hz 7KW
380/220V 50/60Hz 11KW
Dimensions
980*980*2100mm
1610*1210*2180mm
Net Weight
1000KG
2200kg
SNR
<70dB
<70dB



Machine Details

Integrated Vacuum Positioned Capsule Filling Machine With 3 Bores 1Integrated Vacuum Positioned Capsule Filling Machine With 3 Bores 2

Applications

NJP-Series Commercial Scale Capsule Filling Machines is used for Pharmaceutical, medicine, and chemicals (powder, Pellet, granule, pill),also can be used to fill vitamin, foodstuff and animal drug, etc.
1. Touching-Screen, PLC program control panel with LCD.
2. Capsule vacuum positioned mechanism to make the capsule qualified over 99%.
3. Removable powder hopper for cleaning and easy auger adjustment easy to change fills weights.
4. Easy speed selection and closed capsule length adjustment.
5. Quick and accurate change part set-up, easy to remove rotary table and ring carrier assembly.
6. Fully enclosed dosing stations and rotating table for integration of the whole capsule filling plants.
7. Large cam mechanism keeps the rotating table of mould together with the whole equipment running with balance, and completely guarantees the machine operating with highest precision and accuracy.

Integrated Vacuum Positioned Capsule Filling Machine With 3 Bores 3

Integrated Vacuum Positioned Capsule Filling Machine With 3 Bores 4
