    12kw Herb Extraction Equipment , Hemp Oil Extraction And Concentration Equipment

    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE
    Model Number: LTN Series

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiation
    Packaging Details: Wooden Case
    Delivery Time: In 30 days after receiving the deposit
    Payment Terms: 30% TT as deposit and 70% before shipping
    Supply Ability: 25 sets/Month
    Get Best Price Contact Now

    Detail Information

    After-sales Service Provided: Engineers Available To Service Machinery Overseas Raw Material Input Capacity: Ultrasonic Herb Extract Machine
    Power Of Vacuum Pump: 12kw Concentrate Density (%): 1.2-1.35
    The Volume Of Extracting: 6 Raw Material Input Capacity (kg): 600-800
    High Light:

    herbal extraction equipment

    ,

    concentration machine

    Product Description

    12kw Herb Extraction Equipment , Hemp Oil Extraction And Concentration Equipment

    Herb Extract Machine

    This Low Temperature Ethanol Hemp Oil Extraction Machine is applicable for the multiple technology of normal pressure ,micro pressure,water frying ,warm soaking ,thermal reflux,compulsory circulation,filtration,redolent oil extraction and organically solvent recycling in traditional Chinese medicine,food and chemical industry. It is equipped with CIP cleaning device in the tank. solvent extraction



    Main Features

    1. The Low Temperature Ethanol Hemp Oil Extraction Machine consists of extractor, tubular heater, evaporator, condenser, oil-liquid separator, oil collector, medicine liquid pump, weighing vent, liquid storage tank, filter, vacuum pump, and electric cabinet. Defoamers are fixed in the steam outlet of the extractor and evaporator. The units without steam heating can be fixed with oil heating system.

    2. It can be operate to hot recyling distill and condense, normal extraction, concentration, precipitation and percolation.

    3. It can work in the condition of negative pressure, atm. and positive pressure. It can apply to distill water, ethanol and solvent, up to GMP standard.



    4. The Low Temperature Ethanol Hemp Oil Extraction Machine has great advantages in multi-function, high efficiency, energy saving, and wide operation arrange. It pioneers in comprehensive capacity in nationwide; it is the pilot equipment in distilling natural herbal medicine, especially fit for research institution, universities and collages, and factory pilot experiment, or distilling valued medicine, or low temperature fresh herbal. It has been widely used in factories.



    Hempseed oil

    The appearance and characteristics are very close to the low iodine value of linseed oil, but slightly greenish.

    The approximate fatty acid composition is: 10.1% saturated acid, 16% oleic acid, 46% linoleic acid, and 28% linolenic acid.

    The acid value is 3 mg KOH/g, the iodine value is 149-167, and the relative density is 0.925-0.933 (15/15 ° C). The freezing point is about 16 °C.

    The main ingredients are glycerides of linoleic acid, linolenic acid and oleic acid.

    Used in industries such as paints and soaps.



    Machine Main Technical Data:

    Model

    LTN-

    0.1/25

    LTN-

    0.2/50

    LTN-

    0.3/75

    LTN-

    0.5/125

    LTN-

    1/250

    LTN

    -2/500

    LTN

    -3/750

    LTN

    -4/1000

    LTN

    5/1250

    LT

    N6/1500

    The volume of extracting (m³) 0.1 0.2 0.3 0.5 1 2 3 4 5 6
    Raw Material Input Capacity (kg) 10-15 20-30 30-45 50-70 100-150 200-300 300-450 400-600 500-700 600-800
    Capacity of Concentrating Evaporator 25 kg/hour 50 kg/hour 75 kg/hour 125 kg/hour 250kg/hour

    500

    kg/hour

    750

    kg/hour

    1000 kg/

    hour

    1250 kg/hour 1500 kg/hour
    Water Circulation Capacity 10-15T 10-15T 10-15T 10-15T 15-20T 15-20T 15-25T 15-25T 20-30T 20-30T
    The time of extraction (h) 6-8 6-8 6-8 6-8 8 8 8 8 8 8
    Concentrate density (%) 1.2-1.35
    The work temperature of extracting and concentrating (°C) Water: 50-90°C Alcohol: 40-80°C
    Power of Vacuum Pump 3kw 4KW 4.5KW 5KW 6.5kw 8KW 9kw 10kw 11kw 12kw
