Place of Origin:
China
Brand Name:
LTPM China
Certification:
CE, GMP
Model Number:
LTJW-5
Contact Us
Stainless Steel Animal Feed Extrusion Pellet Machine
Function
The extruder LTJW-5 can mix the powder material, excipients and moist adhesives evenly to make the material soft, loose and lumpish. Upon push action of the screw feeder, the material flows into extruding chamber, then passes screen plate through extrusion by extruder, finally forms compact cylindrical extrudants of various lengths.
Technical Data
| Item | Model/specification | Unit |
| Capacity | 5-10 | Kg/h |
| Diameter of pellet | 0.7-3.5(by user) | mm |
| Power | 8.6 | Kw |
| Overall Dimensions | 1550*950*1350 | Mm |
Complete Set
| System | Name | Material | Specification | Place of produce |
| Extruding system | Screw | SUS304 | Ø50 | Haijiang |
| Motor | 1.5KW | China | ||
| Inveter | Siemens | 1.5KW | Germany | |
| Granulating hole cover | SUS304 | Haijiang | ||
| Pelleting system | Rotating motor | 3kw stand model | china | |
| Pelleting chamber | δ=12mm | Haijiang | ||
| Rotor disk | SUS304 |
Ø 400
|
Haijiang | |
| Blower | 1.1 kw volution pump | china | ||
| Inveter | Siemens | 1.1KW | Germany | |
| Control system | Main The part of electric | siemens | germany | |
| Touch screen | Siemens | Siemens7’’ | Germany | |
| PLC | Siemens | Germany |
Doccuments
We will supply this documentation.
One set of IQ and OQ documentations.
One set of user’s manual, which consists in operation, maintenances and troubleshooting.
One set of main components instructions.
Equipment and electrical drawings and so on.
Spare parts list
After-sale service
Customer satisfaction is our pursuit
After-service network all over the world
Customer feedback
Spare parts supply in time
Customer information records
Regular visit service
Product quality guarantee for the users
Final Product
