Electronic automatic tablet counter with Multi 12 Channel and Omron System

Electronic automatic tablet counter with Multi 12 Channel and Omron System

    • Electronic automatic tablet counter with Multi 12 Channel and  Omron System
    • Electronic automatic tablet counter with Multi 12 Channel and  Omron System
  • Electronic automatic tablet counter with Multi 12 Channel and  Omron System

    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE, GMP, SGS, BV
    Model Number: LTEC-12

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiation
    Packaging Details: Export Standard Wooden Case
    Delivery Time: 25days
    Payment Terms: T/T,L/C,D/P
    Supply Ability: 15sets/month
    Contact Now
    Detailed Product Description



    Electronic automatic tablet counter with Multi 12 Channel and Omron System



    Quick Detail:



    LTEC-12 Multi channel Counting machine with vibrating function

    Passed CE Certification up to GMP Standard

    Newly Developed Software Controlling System suitable for different batch of production

    It needs no changing parts while switch product size.





    Description:



         LTEC-12 Automatic Electronic counting machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc. This machine adopts 12 sets imported counting sensor for counting with 12 Guiding Way and two head. The advantage of the machine is no need change mould when you change the counting object, only adjusting the counting table height by Easy Adjust wheel. The machine comes with Touch screen operation and PLC Control for convenient running.





    Applications:



        wide application and use of the Company's original anti-dust photoelectric detection of high technology, can count Tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pill count to bottling;





    Specifications:



    Model Name LTEC-12
    Application

    Filled capsule(00-5#)

    Soft Gelatin capsule

    chewing gum

    tablet

    other solid object under machine range

    Hopper Volume 40L
    Capacity 10-50bottles/min
    Filling Quantity 10-9999pcs/bottle (adjustable)
    Bottle Size

    Diameter: 30-75mm

    Height:40-250mm

    Counting Size

    Thickness: 3-10mm

    Diameter: 3-15mm

    Length: 3-25mm

    Compressed air 0.5Mpa
    Conveyor Belt Length 2400mm
    Machine Weight 650kg
    Machine Size L × W × H (mm) 1450 × 1100 × 1400





    Competitive Advantage:



    1. Compatibility, high accuracy, wide application and use of the Company's original anti-dust photoelectric detection of high technology, can count Tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pill count to bottling;
    2. Vibratory cutting drugs do not damage;
    3. A high degree of intelligence, with no bottle is not the number of self-fault detection alarm and many other control functions;
    4. Compact structure, stability and durability, and no regular replacement parts, small footprint, the use of low-cost;
    5. To facilitate the replacement of species, can automatically take-off and landing, demolition cleared without any tools, convenient and quick;
    6. Chinese dialogue control panel, can store 10 ~ 20 group of species parameters, adjusted to facilitate the use of special;
    7. Fully automatic operation, with the Upper and Lower Union Road, intelligent control of processes, coordination, and no special operation, labor-saving devices.
    8. Low prices, especially for small-volume, variety and more manufacturers use.
    9. Control chip imported to the United States, photoelectric sensors for Taiwan's imports.

    Electronic automatic tablet counter with Multi 12 Channel and  Omron System
