    Three Dimensional Motion Powder Mixing Machine with Electric Control System

    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE, GMP
    Model Number: SYH

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiation
    Packaging Details: Export standard wooden case
    Delivery Time: 25days
    Payment Terms: L/C, T/T
    Supply Ability: 25sets/month
    Get Best Price Contact Now

    Detail Information

    High Light:

    powder mixing equipment

    ,

    powder mixer machine

    Product Description

    Three Dimensional Motion Powder Mixing Machine with Electric Control System

    Three Dimensional Motion Powder Mixing Machine with Electric Control System





    Quick Detail:





    Volume of mixing drum (L):100-1000

    Model No.: SYH

    Max loading volume (L):80-750

    Max loading weight (kg):80-500

    Rotating speed(r/min):10-15

    Power of motor (kw):2.2-11

    Material: Stainless steel 304

    Total Weight: 500-1800 kg

    Power Supply: 380V 50HZ Three Phase

    Certificate: CE Certificate





    Description:





    1. Because the mixing drum has multi directional motion, it makes raw material inside the drum has many       cross-mixing points, therefore the mixing effect is good. Its degree of uniformity may be over 99.9%. its       Max loading efficiency may be 0.9 (The loading efficiency of ordinary mixer is 0.4~0.6). Its mixing time       is short is short and its efficiency is high.
    2. The design of mixing drum is unique. Its inner wall is polished finely. Its advantages are no dead corner,     no pollution to raw material, convenient in discharge, easy in clean and so on..





    Applications:





    This machine is suitable for many industries such as pharmaceutical industry, chemical industry, metallurgy industry, foodstuff industry, architecture industry and institutes. It can mix powder and granule raw materials having good fluidity and make the mixed raw materials reach the best mixing state.





    Specifications:





    Model SYH -100 SYH -200 SYH -400 SYH -600 SYH -800 SYH -1000
    Volume of mixing drum (L) 100 200 400 600 800 1000
    Max loading volume (L) 80 150 300 450 600 750
    Max loading weight (kg) 80 150 200 300 400 500
    Rotating speed(r/min) 15 12 10 10 10 10
    Power of motor (kw) 2.2 3 4 5.5 7.5 11
    Overall dimensions (mm) 1200×1800
    ×1500
    1300×1600
    ×1500
    1500×2200
    ×1500
    1850×2500
    ×1650
    1900×2400
    ×2100
    1950×2500
    ×2400
    Weight (kg) 500 750 1200 1500 16500 1800





    Competitive Advantage:





    1. we have seven technicians who gets passport ready to travel all over world to offer service to you.

    2. We have 24hours hot line for Technical Support.

    3. We get 18hours internet line for technical support.

    4. Video camera in workshop to help you adjust and solve machine problem in working situation.

    5. We have Technical Support in below Foreign Cities:

    California (commission worker), Manila and Davao (Distributor), Lima (Agent), Ho Chi Ming and Hanoi (Agent), Dhaka (Agent), Laho
