Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer

Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer

Product Details:

Place of Origin: China
Brand Name: LTPM China
Certification: CE, GMP
Model Number: LPG Series

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Packaging Details: Export standard wooden case
Delivery Time: 25days
Payment Terms: L/C, T/T
Supply Ability: 25sets/month
Get Best Price Contact Now

Detail Information

Material Consist: Stainless Steel 304 (316 Is Available) Inlet Temperature: 140-350℃(Auto Controled)
Outlet Temperature: 80-90℃ Application: Food,chemical,pharmaceutical Industry
Dust Collect: Included Power Supply: 380V 50Hz
High Light:

Stainless Steel 304 Pharmaceutical Dryers

,

Pharmaceutical Centrifugal Spray Dryer

,

GMP Medicine Extract Centrifugal Spray Dryer

Product Description

Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer

Chinese Traditional Medicine Extract Spray Dryer normally is centrifugal type with closed structure. All parts incontact with materials, product and air inlet are manufactured by high quality stainless steel.By the three gradepurification device, the filtered air could meet requirement of 100,000 class. The wall cooling device is installed tokeep temperature below 80℃, so that the materials will not be coked or deteriorated even stick on the wall.Thepowder collecting efficiency could be highly increased (more than 98-99%).According to product characteristics and customer requirements, air sweeping or wall scraping device can beconfigured correspondingly to improve the yield.According to the characteristics of product and equipment, thepressure type Spray Dryer for Chinese Traditional Medicine Extract is newly developed to avoid wall sticking,improve product quality, simplify the process, increase the particle size and solubility of product.





Principle
Chinese Traditional Medicine Extract Spray Dryer is the centrifugal spray drying technology applied in the dryingof specific material.High speed centrifugal type atomizer is utilized to disperse the materials into mist. After in fullcontact with hot air, the materials complete instant drying to form dry powder products. The product after dryinghas good color and quality.
Spiral-shaped hot air evenly into the drying chamber. By passing through the high-speed centrifugal spray at the top of the tower, the material liquid will rotate and be sprayed into the extremely fine mist liquid beads.Through the very short time of contacting the heat air,the materials can be dried into the finished products. The finished products will separator. The waste gas will be discharged from blower.



Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer 0



Notes:Customers can choose the way of heat in accordance with the conditions of local energy source and the way of dust removing in accordance with the conditions of raw material.



Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer 1

Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer 2



Technical Data



Model

5

25

50

100

150

200-2000

Inlet temperature

350°C

Outlet temperature

80-90°C

Max. evaporation(kg/h)

5

25

50

100

150

200-2000

Centrifugal spraying nozzle transmission mode

compressed air transmission

mechanical transmission

Rotation speed (r.p.m)

25000

22000

21500

18000

18000

15000

Spray disc diameter

50mm

100mm

120mm

140mm

150mm

180-340mm

thermal source

electricity

electricity

electricity + steam, fuel, oil, fuelgas

solved by user

Max. electric heating power (kw)

8

31.5

60

81

99



Overall dimension

1.8*0.93*2.2

3*2.7*4.26

3.7*3.2*5.1

4.6*4.2*6

5.5*4.5*7

optional

Powder recollection (%)

95

95

95

95

95

95



Features
The spray drying is the technology widely used in the liquid technology shaping and in the drying industry. The drying technology
is most suitable for producing the powder, particle or block solid products from the materials, such as: solution, emulsion,
soliquoid and pumpable paste states. For this reason, when the particle size and distribution of the final products, their
residual water contents, the stacking density and the particle shape must meet the precision standard, the spray drying is one of the most desired technologies.At a high speed of drying, after the spraying of the liquid material , the surface area of the material will be increased greatly.In the hot-air flow, 95%-98%of water can be evaporated at a moment. The time of completing the drying needs only several seconds.Products with good uniformity, mobility and solubility, high purity, good quality. The production procedures are simple and the operation and control are easy. The liquid with the moisture contents 40-60%(for special materials, The contents may reach 90%).can be dried into the powder or particle products once a time. After the drying, there is no need for smashing and sorting, so as to reduce the operation procedures in the production and to enhance the product purity. The product particle diameters, looseness and water contents can be adjusted through changing the operation condition in a certain scope. It is very convenient to carry out the control and management.

Compared to ordinary LPG high-speed atomizing dryer,it has the following features:
(1) Adopted three-grade air filter,the inlet air is one hundred thousand grade.
(2) Adopted wall cooling device,the temperature of inner wall will be on more than 80℃.Even if raw material isstayed on the wall, it will not be burnt.
(3) lts whole volume is 3.5 times of standard LPG high-speed atomizing dryer.
(4) Adopted quick washing device, it is can meet the requirements of production for varieties if products.
(5) Adopted wet-dedusting,there is no powder dust out. lt is in conformity with the requirements of GMP.
(6) Adopted air sweeping device , the clean effect is satisfied.
(7) Equipped with two sets of atomizer and adopted frequency inventer control.
(8) Adopted PLC control and display,and adapted frequency control.
(9)Equipped with washing device on request.
(10)Adopted the seal transport by dry air on request.

Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer 3

Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer 4

Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer 5

Product Application

Stainless Steel 304 Pharmaceutical Dryers Centrifugal Spray Dryer 6
