Dia 5mm Cosmetic Cream Tube Filler Sealer Machine 380V For Toothpaste

Dia 5mm Cosmetic Cream Tube Filler Sealer Machine 380V For Toothpaste

Product Details:

Place of Origin: China
Brand Name: LTPM China
Certification: CE
Model Number: LTRG-Series

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: Export Standard Wooden Case
Delivery Time: 25days
Payment Terms: L/C, T/T
Supply Ability: 15Set/Month
Get Best Price Contact Now

Detail Information

Automatic Grade: Automatic Voltage: 220/380V,customized
Usage: Toothpaste,facial Cleanser,foam,cream Filling Speed: 40-60 Pcs/min
Motor: 1.5kw Control System: PLC Control
Weight: 1000KG Tube Diameter: Dia.5mm-60mm
High Light:

Dia 5mm Tube Filler Sealer Machine

,

Tube Filler Sealer Machine 380V

,

Toothpaste Tube Filler Sealer Machine

Product Description

Dia 5mm Cosmetic Cream Tube Filler Sealer Machine 380V For Toothpaste

Dia 5mm Cosmetic Cream Tube Filler Sealer Machine 380V For Toothpaste



Automatic tube filling sealing machine is designed for plastic tube and multiple tube filling and sealing in cosmetic, pharmacy, foodstuff, adhesives etc industries. Its operating principle is to put the pipes which is in the feeder hopper into the first service position filling model individually, to invert with rotating disk, to test nomenclature plate in pipe when inverting to the second , to fill with nitrogen gas into pipe in the third, to fill with desired substance in the fourth, then to fix the heating, folding, jamming, number printing, cooling, slivers trimming etc service position, to export the finished products when inverting to the last service position so the twelfth. Every pipe should take such series process to filling, sealing to completion.

Feature

Compact design
Automatic tube loader feeding tubes
Driving parts fully-closed
Intelligent temperature control and cooling system
Easy to operate and adjust
316l stainless steel contact parts to meet gmp standard
Safety interlock shutdown when door is open
Overload protection provided
Automated working process from tube loading to finished products output
Automatic orientation effected by photoelectric induction
Chiller
Date coding embossing



Optional Devices:
Automatic tube elevator
Change parts for diameter tube
Double layers temperature controlling material hopper
Nitrogen injection function
Mixing at the hopper



Product Application

lt adopt with PLC controller, automatically operating from liquid or high velocity materialfilling till batch number printing (include manufacture date), it's an ideal equipment for ALU tube, plastic tube and multiple tube filling and sealing in cosmetic, pharmacy, foodstuff,adhesives etc industries.

Dia 5mm Cosmetic Cream Tube Filler Sealer Machine 380V For Toothpaste 0







Technical Parameter

Tube Material
Plastic tube, laminated tube
Tube Diameter
Φ5mm-Φ60mm
Tube Length
50-300mm (customizable)
Filling Volume
5-250ml/piece (Adjustable)
Filling Accuracy
≤±1%
Product Capacity (Pcs/min)
30-50 0.1m3/min
Air Supply
0.55-0.65Mpa
Motor Power
1.2kw (380V/220V 50Hz)
Heat Sealing Power
5kw



Dia 5mm Cosmetic Cream Tube Filler Sealer Machine 380V For Toothpaste 1
