Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy

Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy

Product Details:

Place of Origin: China
Brand Name: LTPM China
Certification: CE
Model Number: ZP-31D

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Wooden Case
Delivery Time: In 25 days after receiving the deposit
Payment Terms: 30% TT as deposit and 70% before shipping
Supply Ability: 25 sets/Month
Get Best Price Contact Now

Detail Information

Capacity: 45,000-110,000tablets/hour Material Consist: Painted Matel
Max. Thickness: 6mm Max.Diameter: 12mm
Max.Pressure: 40KN Power: 2.2Kw
Weight: 60KG Warranty: 5 Years
High Light:

Candy Rotary Tablet Press Machine

,

Rotary Tablet Press Machine 40KN

,

Painted Metal Tablet Press Machine

Product Description

Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy

Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy



Knowledge of tablet ingredients before you start tableting.

There are thousands of powder types. According to our factory's many years of experience, most of the raw materials are suitable for tabletting, or after simple processing, they are suitable for tabletting. Some raw materials are not suitable for tabletting.

Please refer to the following elements or consult customer service whether it is suitable for tabletting, please read it carefully, so as not to cause your loss due to withdrawal due to raw material problems.





Suitable for tablet material requirements:

1. Dry powder: The raw material must be dry powder and the moisture content must be controlled within 5%.

2. Fluidity: The raw material needs to have good fluidity (ideally the particle size of the tablet material is preferably between 20 and 60 mesh, and a small amount of fine powder is better). If the raw material fluidity is not good, it can be solved by making particles.

3. Adhesiveness: Tackiness means that the powder can form agglomerates or the powder can stick together by external forces. For non-sticky raw materials, it may be necessary to increase the binder to improve (such as maltodextrin, starch, sugar, microcrystalline cellulose, etc.)

4. Does not contain a large amount of oil: Raw materials containing a large amount of oil are difficult to form, so the material must not contain too much oil.

If you are not sure whether your raw materials are suitable for tabletting, you can send us the raw materials and we will help you test the machine.



Main Technical Parameters

Model
TDP-1.5
TDP-5
TDP-6
Max. Pressure
1.5T
5T
6T
Max. Dia.
Round: Φ12
Round: Φ20
Round: Φ25
Max. Filling Depth
11mm
18mm
18mm
Max. Thickness
6mm
7.5mm
7.5mm
Capacity
5000pcs/hour
4500pcs/hour
3000pcs/hour
Motor Power
550W
750
800
Overall Dimension
580×450×625 mm
650×440×650mm
750×380×659mm
Weight
100kg
120kg
165kg





Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy 0Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy 1

Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy 2

Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy 3

Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy 4



Machine Details

Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy 5

Single Punch Painted Metal Rotary Tablet Press Machine 40KN For Candy 6
