CBD Oil Short Path Molecular Distiller Equipment For Hemp Oil Extraction

CBD Oil Short Path Molecular Distiller Equipment For Hemp Oil Extraction

    • CBD Oil Short Path Molecular Distiller Equipment For Hemp Oil Extraction
    • CBD Oil Short Path Molecular Distiller Equipment For Hemp Oil Extraction
  • CBD Oil Short Path Molecular Distiller Equipment For Hemp Oil Extraction

    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE
    Model Number: LTSP-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiation
    Packaging Details: Wooden Case
    Delivery Time: In 30 days after receiving the deposit
    Payment Terms: 30% TT as deposit and 70% before shipping
    Supply Ability: 25 sets/Month
    Contact Now
    Detailed Product Description
    Evaporation Area M2: 1 Feeding Rate L/h: 50-120
    Feeding Method: High-precision Gear Pump Receiving Method: Continuous Discharge Pump
    Equipment Height(mm): 4250 Max Speed(rpm): 50-350
    Operation Temperature: Up To 350C Vacuum Level(mbar): Low To 0.001 Mbar
    Feeding Mode: Gear Pump For Automatic And Continuous Feeding Collection Mode: Gear Pump For Automatic And Continuous Collection



    CBD Oil short path molecular distiller equipment For hemp oil extraction



    Advantages of LTPM CHINA Instrument:

    (1) The molecular distillation vacuum is high, the operating temperature is low and the heating time is short. for the separation od material with high boiling point , heat sensitive and easy to oxidize, It can be an excellent guarantee of the natural quality of the material.It has been widely used in the extraction of natural substances.
    (2) Molecular distillation can not only effectively remove low-molecular substances in the liquid, such as: organic solvents, odor, etc., But alsp selectively evaporate the target product, remove other impurities,.So It is considered a natural quality of the protector and return The
    (3) Molecular distillation can achieve the physical process which traditional separation method can not achieve.Therefore, on the separation of some high-value materials is widely used as deodorization, decolorization and purification means.



    LTPM CHINA Instrument develop stainless steel wiped film molecular distillation based on customer's production needs. Its efficient productivity can help customers save costs to the the greatest extent

    1. Modularized design for flexible options
    2. Continuous feeding & collection modules design, saving labor cost and working time
    3. Fully jacketed design, wide applications for different materials
    4. SUS316L stainless steel, safe and reliable
    5. Sight glass and quick connect design, easy to disassemble and clean



    Technical data:

    Turnkey Solution for Stainless Steel Molecular Distillation
    Model LTSP-1 LTSP-2 LTSP-5 LTSP-10 LTSP-15 LTSP-20 LTSP-30 LTSP-50
    Evaporation Area m2 0.1 0.2 0.5 1 1.5 2 3 5
    Feeding Rate L/h 1-15 5-25 10-60 50-120 60-180 100-200 100-300 200-500
    Feeding Method High-precision gear pump
    Receiving Method Continuous discharge pump
    Equipment Height(mm) 2100 2650 3100 4250 4500 5000 6200 7500
    Max Speed(rpm) 50-350
    Operation Temperature Up to 350C
    Vacuum Level(mbar) Low to 0.001 mbar
    Feeding Mode Gear pump for automatic and continuous feeding
    Collection Mode Gear pump for automatic and continuous collection













































    Laboratory apparatus short path distillar molecular distillation:
    *All Borosilicate 3.3 glass design for a perfect view on the separation process.
    *Short residence time(separation is finished in seconds, instead of hours.).

    *The very low operating pressure ensure very low distillation temperature and therefore a very gentle distillation is possible.
    *Various size options(60mm,100mm,150mm) for different throughput).
    *The system can be upgraded for continuous distillation process.
    *Industrial grade(>=200mm) products are available upon request.



    CBD Oil Short Path Molecular Distiller Equipment For Hemp Oil Extraction
