    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE
    Model Number: LTSP-30

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiation
    Packaging Details: Wooden Case
    Delivery Time: In 30 days after receiving the deposit
    Payment Terms: 30% TT as deposit and 70% before shipping
    Supply Ability: 25 sets/Month
    Contact Now
    Detailed Product Description
    Evaporation Area M2: 3 Feeding Rate L/h: 100-300
    Feeding Method: High-precision Gear Pump Receiving Method: Continuous Discharge Pump
    Equipment Height(mm): 6200 Max Speed(rpm): 50-350
    Operation Temperature: Up To 350C Vacuum Level(mbar): Low To 0.001 Mbar
    Feeding Mode: Gear Pump For Automatic And Continuous Feeding Collection Mode: Gear Pump For Automatic And Continuous Collection



    CBD Hemp Oil Low Temperature Short Path Molecular Distiller Extraction



    Features:

    Molecular distillation, also called molecular distiller, it is a process of separation, purification and concentration of natural products, complex and thermally sensitive molecules for example vitamins and polyunsaturated fatty acids. This process is characterized by short term exposure of the distillate liquid to high temperatures, by high vacuum pressure (around 1024 mmHg) in the distillation column and a small distance between the evaporator and the condenser around 2 cm, where fluids are in the free molecular flow regime, i.e. the mean free path of molecules is comparable to the size of the equipment. This process has the advantages of avoiding the problem of toxicity that occurs in techniques that use solvents as the separating agent, and also of minimizing losses due to thermal decomposition.




    short path molecular distillation equipment:

    1. Economical and practical.
    2. For viscous material, the feeding tank is designed as a double layer insulation tank, all tube parts are double-layer insulation type, ensure there will be no solidification which will affect material's separation.
    3. Double-layer insulation feeding tank, continuous feeding of magnetic gear pump, light phase and heavy phase sample magnetic circulation gear pump continuous collection scheme.



    Low Temperature Short Path Molecular Distiller CBD Hemp Oil Extraction

















































































    Technical data:

    Turnkey Solution for Stainless Steel Molecular Distillation
    Model LTSP-1 LTSP-2 LTSP-5 LTSP-10 LTSP-15 LTSP-20 LTSP-30 LTSP-50
    Evaporation Area m2 0.1 0.2 0.5 1 1.5 2 3 5
    Feeding Rate L/h 1-15 5-25 10-60 50-120 60-180 100-200 100-300 200-500
    Feeding Method High-precision gear pump
    Receiving Method Continuous discharge pump
    Equipment Height(mm) 2100 2650 3100 4250 4500 5000 6200 7500
    Max Speed(rpm) 50-350
    Operation Temperature Up to 350C
    Vacuum Level(mbar) Low to 0.001 mbar
    Feeding Mode Gear pump for automatic and continuous feeding
    Collection Mode Gear pump for automatic and continuous collection











































    Low Temperature Short Path Molecular Distiller CBD Hemp Oil Extraction
