Product Details:

Place of Origin: China
Brand Name: LTPM China
Certification: CE
Model Number: LTN Series

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: Wooden Case
Delivery Time: In 30 days after receiving the deposit
Payment Terms: 30% TT as deposit and 70% before shipping
Supply Ability: 25 sets/Month
Get Best Price Contact Now

Detail Information

After-sales Service Provided: Engineers Available To Service Machinery Overseas Raw Material Input Capacity: Ultrasonic Herb Extract Machine
Power Of Vacuum Pump: 12kw Concentrate Density (%): 1.2-1.35
The Volume Of Extracting: 6 Raw Material Input Capacity (kg): 600-800
High Light:

concentration machine

,

liquid extraction equipment

Product Description

Herb Extract Machine

Applications:
This multifunction extraction tank can be used in herb, plant, pharmaceuticals, food and chemical industry, water decoction, atmospheric wet leaching, heat reflux forced circulation, penetration, plant essential oils and aromatic oil extraction and organic solvent recycle in atmospheric pressure and micro pressure.
The multifunction extractor is suitable for colleges and universities, research institutes, laboratories, pharmaceutical factory etc. multi variety material and small batch production.



Component
1) The equipment is compact conformed and integrated with extraction, oil-water separation device, condenser, cooling tank, concentration tank, and solvent recovery tank.
2) Synchronous in Extraction and concentration process shorten the technical process and production period, increasing the operation rate of the equipment.

Advantage
1) Add the solvent once for all, with the consumption lowered by more than 40%. With hot reflux, forced circulation and sox let extraction integrated, the solute keeps high gradient in the solvent, increasing the receiving rate by 10 to15%.

2) Connecting and reusing the condenser make the equipment compact-conformed and bring each part into full play. Without increasing investment of the device, Both the reflux and solvent recovery can be reached to good effect.

3) New technology and new materials are utilized for excellent performance of unit. The areas of the unit contacting with medical liquids and solvents in instruments, equipments and pipes, are made of superior stainless steel.



Hempseed oil

The appearance and characteristics are very close to the low iodine value of linseed oil, but slightly greenish.

The approximate fatty acid composition is: 10.1% saturated acid, 16% oleic acid, 46% linoleic acid, and 28% linolenic acid.

The acid value is 3 mg KOH/g, the iodine value is 149-167, and the relative density is 0.925-0.933 (15/15 ° C). The freezing point is about 16 °C.

The main ingredients are glycerides of linoleic acid, linolenic acid and oleic acid.

Used in industries such as paints and soaps.



Machine Main Technical Data:

Model

LTN-

0.1/25

LTN-

0.2/50

LTN-

0.3/75

LTN-

0.5/125

LTN

-1/250

LTN-

2/500

LTN

-3/750

LTN-4/1000 LTN5/1250 LTN6/1500
The volume of extracting (m³) 0.1 0.2 0.3 0.5 1 2 3 4 5 6
Raw Material Input Capacity (kg) 10-15 20-30 30-45 50-70 100-150 200-300 300-450 400-600 500-700 600-800
Capacity of Concentrating Evaporator 25 kg/hour

50 kg/

hour

75 kg/

hour

125 kg/

hour

250kg/

hour

500kg/

hour

750kg

/hour

1000 kg/hour 1250 kg/hour 1500 kg/hour
Water Circulation Capacity 10-15T 10-15T 10-15T 10-15T 15-20T 15-20T 15-25T 15-25T 20-30T 20-30T
The time of extraction (h) 6-8 6-8 6-8 6-8 8 8 8 8 8 8
Concentrate density (%) 1.2-1.35
The work temperature of extracting and concentrating (°C) Water: 50-90°C Alcohol: 40-80°C
Power of Vacuum Pump 3kw 4KW 4.5KW 5KW 6.5kw 8KW 9kw 10kw 11kw 12kw



Chinese Medicine Hemp Extraction Machine Membrane Concentrating Equipment 0Chinese Medicine Hemp Extraction Machine Membrane Concentrating Equipment 1Chinese Medicine Hemp Extraction Machine Membrane Concentrating Equipment 2
