Place of Origin:
China
Brand Name:
LTPM China
Certification:
CE
Model Number:
LTN Series
Contact Us
Applications:
This multifunction extraction tank can be used in herb, plant, pharmaceuticals, food and chemical industry, water decoction, atmospheric wet leaching, heat reflux forced circulation, penetration, plant essential oils and aromatic oil extraction and organic solvent recycle in atmospheric pressure and micro pressure.
The multifunction extractor is suitable for colleges and universities, research institutes, laboratories, pharmaceutical factory etc. multi variety material and small batch production.
Working principle:
Extracting principle: when extracting, the tank heated indirectly with heat conducting oil in jacket, set the extracting tank material temperature and boiler temperature. The stirring speed is adjustable. The steam generated in the tank enter condenser and after condensation, back to oil-water separator, water liquid reflux to extraction tank, oil discharge through the optic cup from the discharge port, such cycle until the termination of extraction. After extraction, the extracting solution through the pump into the pipeline filter, clear liquid into the concentration tank.
Features:
1. This multifunction extraction tank is high efficiency, is the latest developed small dynamic extraction tank, saving raw material and working time is 10%~15% higher than the general extraction tank.
2. Raw material conversion rate is high, in the process of extraction hot solvent (water or alcohol etc.) continuously added to the raw material medicine, effective components from the material continuous dissolution from top to bottom, make the effective components in original liquid twice as general extraction tank.
3. The extraction tank use paddle stirring, make large volume herb can fully exposed to solvents, accelerate the precipitation of effective components in the raw materials.
4. This dynamic extractor has large aperture manhole or hand hole, convenient for taking herb dregs, and has filter system, prevent fine dregs to flow to the concentration unit.
5. The extraction tank has compact structure, small occupation area, the actual area about 2 m2, convenient to operate.
6. This extraction tank is not limited by herb components polar and molecular size, suitable for most herb materials. Adopts full closed inner circulation structure, has oil-water separator, condenser and cooler, can extract aromatic oil and vegetable essential oil at high efficiency.
Hempseed oil
The appearance and characteristics are very close to the low iodine value of linseed oil, but slightly greenish.
The approximate fatty acid composition is: 10.1% saturated acid, 16% oleic acid, 46% linoleic acid, and 28% linolenic acid.
The acid value is 3 mg KOH/g, the iodine value is 149-167, and the relative density is 0.925-0.933 (15/15 ° C). The freezing point is about 16 °C.
The main ingredients are glycerides of linoleic acid, linolenic acid and oleic acid.
Used in industries such as paints and soaps.
Machine Main Technical Data:
| Model |
LTN- 0.1/25 |
LTN- 0.2/50 |
LTN- 0.3/75 |
LTN- 0.5/125 |
LTN -1/250 |
LTN -2/500 |
LTN- 3/750 |
LTN -4/1000 |
LTN5 /1250 |
LTN6 /1500 |
|
| The volume of extracting (m³) | 0.1 | 0.2 | 0.3 | 0.5 | 1 | 2 | 3 | 4 | 5 | 6 | |
| Raw Material Input Capacity (kg) | 10-15 | 20-30 | 30-45 | 50-70 | 100-150 | 200-300 | 300-450 | 400-600 | 500-700 |
600- 800 |
|
| Capacity of Concentrating Evaporator | 25 kg/hour | 50 kg/hour | 75 kg/hour | 125 kg/hour | 250kg/hour | 500kg/hour | 750kg/hour | 1000 kg/hour | 1250 kg/hour | 1500 kg/hour | |
| Water Circulation Capacity | 10-15T | 10-15T | 10-15T | 10-15T | 15-20T | 15-20T | 15-25T | 15-25T | 20-30T | 20-30T | |
| The time of extraction (h) | 6-8 | 6-8 | 6-8 | 6-8 | 8 | 8 | 8 | 8 | 8 | 8 | |
| Concentrate density (%) | 1.2-1.35 | ||||||||||
| The work temperature of extracting and concentrating (°C) | Water: 50-90°C Alcohol: 40-80°C | ||||||||||
| Power of Vacuum Pump | 3kw | 4KW | 4.5KW | 5KW | 6.5kw | 8KW | 9kw | 10kw | 11kw | 12kw | |
