Chemical Industry Stainless Steel Evaporation Concentrator Hemp Oil Low Noise
Product Details:
Place of Origin: | China |
Brand Name: | LTPM China |
Certification: | CE |
Model Number: | LTN Series |
Payment & Shipping Terms:
Minimum Order Quantity: | 1set |
---|---|
Price: | Negotiation |
Packaging Details: | Wooden Case |
Delivery Time: | In 30 days after receiving the deposit |
Payment Terms: | 30% TT as deposit and 70% before shipping |
Supply Ability: | 25 sets/Month |
Detail Information |
|||
After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Raw Material Input Capacity: | Ultrasonic Herb Extract Machine |
---|---|---|---|
Power Of Vacuum Pump: | 12kw | Concentrate Density (%): | 1.2-1.35 |
The Volume Of Extracting: | 6 | Raw Material Input Capacity (kg): | 600-800 |
High Light: | herbal extraction equipment,concentration machine |
Product Description
Herb Extract Machine
Product Application
Better Industry can supply the ethanol extraction system with winterization and solvent recovery functions, the capacity in the range of 100--53,000 lbs biomass per day for each system. We also can customize the system with wiped film ,centrifuge, 2 micro fine filter.
Our factory was engaged in herb extraction in China for more than 18years . The CBD solution was supplied to the international customers since 2015. If you are looking for a CBD system with big capacity, we are the right one to talk with you . Suggest you visit us face to face ,so many copies by internet, we cant put more information to share here, hope you understand !
Main Features
1. The Hemp Oil Ethanol Extractor consists of extractor, tubular heater, evaporator, condenser, oil-liquid separator, oil collector, medicine liquid pump, weighing vent, liquid storage tank, filter, vacuum pump, and electric cabinet. Defoamers are fixed in the steam outlet of the extractor and evaporator. The units without steam heating can be fixed with oil heating system.
2. It can be operate to hot recyling distill and condense, normal extraction, concentration, precipitation and percolation.
3. It can work in the condition of negative pressure, atm. and positive pressure. It can apply to distill water, ethanol and solvent, up to GMP standard.
4. The Hemp Oil Ethanol Extractor great advantages in multi-function, high efficiency, energy saving, and wide operation arrange. It pioneers in comprehensive capacity in nationwide; it is the pilot equipment in distilling natural herbal medicine, especially fit for research institution, universities and collages, and factory pilot experiment, or distilling valued medicine, or low temperature fresh herbal. It has been widely used in factories.
How it Works:
- Put the prepared materials into the extracting tank, and add solvent 5-10 times the volume of the materials ( the actual type and the amount of solvent is according to the process requirement).
- After soaking for a certain while, open the steam valve to heat up, normally by jacket heating, steam heating is only for water extraction and drawing aromatic oil.
- After cooking for a certain while, pump the extraction solution into the concentrator.
Hempseed oil
The appearance and characteristics are very close to the low iodine value of linseed oil, but slightly greenish.
The approximate fatty acid composition is: 10.1% saturated acid, 16% oleic acid, 46% linoleic acid, and 28% linolenic acid.
The acid value is 3 mg KOH/g, the iodine value is 149-167, and the relative density is 0.925-0.933 (15/15 ° C). The freezing point is about 16 °C.
The main ingredients are glycerides of linoleic acid, linolenic acid and oleic acid.
Used in industries such as paints and soaps.
Machine Main Technical Data:
Model |
LTN- 0.1/25 |
LTN- 0.2/50 |
LTN- 0.3/75 |
LTN- 0.5/125 |
LTN- 1/250 |
LTN -2/500 |
LTN -3/750 |
LTN- 4/1000 |
LTN5/1250 | LTN6/1500 | |
The volume of extracting (m³) | 0.1 | 0.2 | 0.3 | 0.5 | 1 | 2 | 3 | 4 | 5 | 6 | |
Raw Material Input Capacity (kg) | 10-15 | 20-30 | 30-45 | 50-70 | 100-150 | 200-300 | 300-450 | 400-600 | 500-700 | 600-800 | |
Capacity of Concentrating Evaporator | 25 kg/hour |
50 kg/ hour |
75 kg/ hour |
125 kg/ hour |
250kg /hour |
500kg /hour |
750kg/hour |
1000 kg/ hour |
1250 kg/hour | 1500 kg/hour | |
Water Circulation Capacity | 10-15T | 10-15T | 10-15T | 10-15T | 15-20T | 15-20T | 15-25T | 15-25T | 20-30T | 20-30T | |
The time of extraction (h) | 6-8 | 6-8 | 6-8 | 6-8 | 8 | 8 | 8 | 8 | 8 | 8 | |
Concentrate density (%) | 1.2-1.35 | ||||||||||
The work temperature of extracting and concentrating (°C) | Water: 50-90°C Alcohol: 40-80°C | ||||||||||
Power of Vacuum Pump | 3kw | 4KW | 4.5KW | 5KW | 6.5kw | 8KW | 9kw | 10kw | 11kw | 12kw |
