Place of Origin:
China
Brand Name:
LTPM China
Certification:
CE
Model Number:
LTN Series
Contact Us
This Low Temperature Ethanol Hemp Oil Extraction Machine is applicable for the multiple technology of normal pressure ,micro pressure,water frying ,warm soaking ,thermal reflux,compulsory circulation,filtration,redolent oil extraction and organically solvent recycling in traditional Chinese medicine,food and chemical industry. It is equipped with CIP cleaning device in the tank. solvent extraction
Application :
Chinese herb plant extraction
herb extraction and concentration
This equipment is suitable for traditional herb medicine, health products, biological, pharmaceutical, cosmetic and food industries heating atmospheric temperature of extraction, extraction, dynamic hot reflux extraction, vacuum concentration, and organic solvent recovery and so on the many kinds of craft. This equipment can be dynamic continuous extraction and vacuum concentration at the same time. This equipment is very suitable for the laboratory research and development departments of universities, research institutes, enterprises and institutions as well as for the production and use of multiple varieties and small batches of pharmaceutical factories.
Ultrasonic solvent extraction machine,as our core products,has agglomerated many new technologies such as ultrasonic extraction,dynamic counter-flow extraction,low temperature concentration,high efficient recovery of organic solvent,specific machanic seals etc.The machine realizes fast extraction production under low and normal temperature through the whole process.It is used most suitable for extracting and producing in different scale of heat sensitive extracts by organic solvent.
1.Used for essential oil making
2.Wide using for plant essential oil making
3.Combine ultrasonic,water,alcohol and other organic solvent extraction
Hempseed oil
The appearance and characteristics are very close to the low iodine value of linseed oil, but slightly greenish.
The approximate fatty acid composition is: 10.1% saturated acid, 16% oleic acid, 46% linoleic acid, and 28% linolenic acid.
The acid value is 3 mg KOH/g, the iodine value is 149-167, and the relative density is 0.925-0.933 (15/15 ° C). The freezing point is about 16 °C.
The main ingredients are glycerides of linoleic acid, linolenic acid and oleic acid.
Used in industries such as paints and soaps.
Machine Main Technical Data:
| Model |
LTN- 0.1/25 |
LTN- 0.2/50 |
LTN- 0.3/75 |
LTN- 0.5/125 |
LTN- 1/250 |
LTN -2/500 |
LTN-3/750 | LTN-4/1000 |
LTN5 /1250 |
LTN6 /1500 |
|
| The volume of extracting (m³) | 0.1 | 0.2 | 0.3 | 0.5 | 1 | 2 | 3 | 4 | 5 | 6 | |
| Raw Material Input Capacity (kg) | 10-15 | 20-30 | 30-45 | 50-70 | 100-150 | 200-300 | 300-450 | 400-600 | 500-700 | 600-800 | |
| Capacity of Concentrating Evaporator | 25 kg/hour |
50 kg/ hour |
75 kg/ hour |
125 kg/ hour |
250 kg/hour |
500 kg/hour |
750 kg/hour |
1000 kg/hour | 1250 kg/hour | 1500 kg/hour | |
| Water Circulation Capacity | 10-15T | 10-15T | 10-15T | 10-15T | 15-20T | 15-20T | 15-25T | 15-25T | 20-30T | 20-30T | |
| The time of extraction (h) | 6-8 | 6-8 | 6-8 | 6-8 | 8 | 8 | 8 | 8 | 8 | 8 | |
| Concentrate density (%) | 1.2-1.35 | ||||||||||
| The work temperature of extracting and concentrating (°C) | Water: 50-90°C Alcohol: 40-80°C | ||||||||||
| Power of Vacuum Pump | 3kw | 4KW | 4.5KW | 5KW | 6.5kw | 8KW | 9kw | 10kw | 11kw | 12kw | |
