    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE, GMP
    Model Number: MT

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiation
    Packaging Details: Export standard wooden case
    Delivery Time: 25days
    Payment Terms: L/C, T/T
    Supply Ability: 25sets/month
    Contact Now
    Detailed Product Description
    After-sales Service Provided: Engineers Available To Service Machinery Overseas The Standard System: Step Motor
    Capacity: 20-130 Carton/min Labeling Accuracy: ±1.0mm (subject To The Roughness Of The Plane)
    Weight: 200kgs Power Supply: AC220V 50/60HZ Single Phase

    GMP Sleeve Automatic Labeling Machine , Packing Bottle Labeling Machine

    Product Description

    Summary:

    MT-130D model vertical type round bottle non-dry tape marking machine, in order to achieve rationalization of production target and design. Labeling process automation, simple operation, the production speed is quick, labeling position, beautiful, neat, For pharmaceutical, chemical and foodstuff trades etc circular vessels labeling.

    Working principle:

    The machine can packing different objects into labeling machine belt conveyor, by driving a bottle into the bottle conveying institutions, continuous motion by depending on fiber detected after bottle, photoelectric signal transmission to PLC, by PLC output signal processing will lose to the stepping motor, the standard of stepping motor, through the rolling institutions will stick son, tag labeling of objects by labeling machine conveyor belt into the next procedure or containers.

    Main machine running adopts stepping motor driver, sets of (Taiwan) PLC control system, sets of (Taiwan) touch screen, keyence fiber (Japan) device etc imported components, gathers numerous leading technology, make it become the industry has the advantage of technology products.

    Microcomputer automatic control, interface screen friendly human-machine interface, ingenious mechanical structure, make the operation simple and powerful function, Can realize tag number, counting, set print control, labeling, lack of control, marking, colorless such abnormalities automatic detection and alarm functions, Random capacity and the quantity management label, Adjust tightness labels, The length and tags, Host height and adjust position before, Optional ribbon typewriter one, Labeling and tag with reaction degree detection.

    The machine adopts high-quality T6 aluminum and stainless steel SUS304, well made, in conformity with the requirements of GMP.

    Technical Parameters:

    Model MT-130D
    The standard system Step Motor
    Capacity 20-130 carton/min
    Operating Direction Left or right
    Label speed ≤35 m/min
    Tags volume inner diameter 76 mm
    Tags volume outer diameter 350 mm (max)
    Label Specifications Glassine backing Paper , opaque label (The application of carton Can be customized according to customer’s demand)
    Labeling accuracy ±1.0mm (subject to the roughness of the plane)
    Weight 200KGS
    Total motor power 800W
    Power supply AC220V 50/60HZ Single phase
    Size appearance (mm) 2200 (L) 1800 (W) 1500(H)
    GMP Sleeve Automatic Labeling Machine , Packing Bottle Labeling Machine








































    Packaging & Shipping



    Packaging Details:

    MT-130D Carton Double Sides Sticker Labeling Machine wrapped with strech film packed into export tandard wooden case for anti moisture can afford long time sea shipment

    Delivery Detail:

    within 25days after receive your deposit

    Our Services

    Installation and after sales service:

    Installing and Commission: We will install and test the machine in best working condition before shipment. If customer requires our technician to adjusting the machine and train technician at arrival place, we will send technician there. All our expenses including round-trip air ticket to the nearest airport, local conveyance to your factory, Lodging & Boarding expenses shall be payable by you. In case the stay of our technician, the service charges US $ 50 per day will be charged extra.

    Warranty Period: There is one year for fully machine guarantee.

    And in this year if the machine broken caused by Mechanical problem, all of the spare part is free. The service of the machine all though the machines life.

    After sales service: 1. we have seven technicians who gets passport ready to travel all over world to offer service to you

    2. We have 24hours hot line for Technical Support.

    3. We get 18hours internet line for technical support.

    4. Video camera in workshop to help you adjust and solve machine problem in working situation.



    Company Information

    Cerification and Documents of the machines:



    FAQ

    For More Details, please contact us by mail or telephone. You are so the most welcome here to visit our manufacturing plant!

    LTPM CHINA, Your Best Pharmaceutical Production Solution!
