NJP Capsule Filling Equipment , Automatic Capsule Filler High Performance

NJP Capsule Filling Equipment , Automatic Capsule Filler High Performance

capsule filler machine

automatic capsule filler

Place of Origin:

china

Brand Name:

LTPM CHINA

Certification:

CE

Model Number:

NJP-2000

Contact Us

Request A Quote
Product Details
Capacity:
1000capsules/minute
Bores:
18
Operation:
Touch Screen
Power Supply:
415v 50Hz Three Phase (it Can Be Changed Depend On Your Requirement)
Material Consist:
Stainless Steel 304 And 316L
Product Description

NJP Capsule Filling Equipment , Automatic Capsule Filler High Performance

Product Description



MODEL 2000C
Output(pcs./min) 2000
No. of segment bores 18
Applicable Capsule Size 00#-5#
Applicable Filling Object Powder and granular ( Pellets is available)
Operation System Touch screen (Button operation is available)
Dosage Different Dosages are available by changing dosage disk
Power Supply Customerized
Total Power 7.62KW
Overall Weight 1800Kg
Overall Dimension(mm) 1375×1345×2000(+200)mm




1. Feature:
1). Good looking appearance, exquisite workmanship, ease of operation, simplicity of use.
2). Stowage seat and dosage tray are designed as on unit to make dosage tray and stowage rod without deviation phenomenon, avoid friction phenomenon between stowage rod and dosage tray, improve its precision highly, furthermore, it delays the machines use life greatly.
3). In allusion to sticky or fluidity powder cause bad filling effect, in the dosage tray designed a powder scraper to improve the precision of filling.
4). Other device designed to avoid disqualified capsules get into mould caused by sticky powder, and this improves rate of finished products.
5). Ineligible capsule can be eliminated automatically, the medicine in the capsule can be recycled and reused, thus it can increase economic benefit greatly.
6). Simplicity and convenience of dismantling, installation and clean, various models of mould can be replace each other, the mould of 800, 1000, 1200 can be interchange on the same machine to meet different requirement of capacity.
7). Dust collector and vacuum pipe as well as waste air pipe are installed in the inner of the machine, avoid the air pipe becoming hard, broken or leakage etc phenomenon, it is more convenient to clean the platform. Furthermore, it accords GMP requirement.
8). The cap of stowage rod is made of stainless steel to replace original plastic cap to avoid breaking phenomenon; on the other hand, the screws and caps on the platform lesser to make the whole appearance more good looking.
9). Suitable for domestic capsules, its filling ration no less than 99%.
10). The main spare parts such as starting shaft, cam etc are adopted the imported materials.


Our Services


1. 24*7days hotline service.
2. Technology Support: we offer engineer at site training and intsllation service all over the world.
3. Documentation: DQ, IQ, OQ, PQ, FAT, SAT, Manual, etc for GMP validation purpose.
4. One year spare parts Free Guarantee
5. Production Solution Suggestion
