Vertical Ampoule And Vial Ultrasonic Bottle Washing Machine QCL Series

Vertical Ampoule And Vial Ultrasonic Bottle Washing Machine QCL Series

    • Vertical Ampoule And Vial Ultrasonic Bottle Washing Machine QCL Series
    • Vertical Ampoule And Vial Ultrasonic Bottle Washing Machine QCL Series
    • Vertical Ampoule And Vial Ultrasonic Bottle Washing Machine QCL Series
    • Vertical Ampoule And Vial Ultrasonic Bottle Washing Machine QCL Series
    • Vertical Ampoule And Vial Ultrasonic Bottle Washing Machine QCL Series
  • Vertical Ampoule And Vial Ultrasonic Bottle Washing Machine QCL Series

    Product Details:

    Place of Origin: China
    Brand Name: LTPM China
    Certification: CE, GMP, SGS, BV
    Model Number: LX40/60/80

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: Negotiation
    Packaging Details: Export Standard Wooden Case
    Delivery Time: 25days
    Payment Terms: T/T,L/C,D/P
    Supply Ability: 15sets/month
    Contact Now
    Detailed Product Description
    Cleaning Heads: 40/60/80 Packaging Type:: Bottles
    Dimension(L*W*H):: 2070*2100*1300 Capacity:: 12,000-24,000pcs/hou
    The Rate Of Bottle Breakage:: <2‰ Specifications: 10-30mm

    +1_01

    Description:

    Vertical turntable structure,clamping bottle with manipulator,turning,and washing nozzle tracking movement,high washing efficiency.

    Ultrasonic washing can remove the adherent matter inside the bottle and outer surface of bottle.

    Automatic control water level and water temperature,constant temperature to make sure good efficency of ultrasonic washing.

    All the washing process are completed in the sealed condition , which can avoid crossover contamination and complies with GMP standard.

    Solenoid-controlled valve control the on-off time of flushing water,air charging,it can save water,air consumption.

    Imported PLC,automatic production can be realized.

    Touch screen operated panel,convenient and beautiful.

    Inverter stepless speed regulation.

    Main Technical Data:



    Product model LX40 LX60 LX80
    Specifications 10-30mm 10-30mm 10-30mm
    Cleaning head 40 60 80
    Productive capacity(bottle/hour) ~12000 ~21000 ~24000
    Cleaning medium Spraying water 0.6m³/h 0.15MPa 0.9m³/h 0.15MPa 0.8m³/h 0.15MPa
    Compre ssedair 40m³/h 0.1MPa 50m³/h 0.1MPa 40m³/h 0.1MPa
    The rate of bottle breakage <2‰
    Electric power(Kw) 12.35Kw,AC380V,50Hz 12.35Kw,AC380V,50Hz 13Kw,AC380V,50Hz
    Total weight(Kg) 1800 1850 2200
    Overall dimensions(L*W*H) 2070*2100*1300 2070*2100*1300 2070*2100*1300



    Comptitive Advantage:

    1. 21years Liquid Solution machinery manufacturing experience

    2. <2‰ Breakage with high accurate working

    3. Simple Changing parts style

    4. Able to connect with drying and sterilizing machine.







    +1_02

    +1_04

    +1_05

    +1_06

    +1_07

    +1_08

    +1_09

    +1_10

    Q: What price terms you offer?

    A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.



    Q: What payment terms you take?

    A: TT, LC, other terms are also workable.



    Q: Will you help with installation and stuff training?

    A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.



    Q: How can I visit your factory?

    A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange everything for you!
    Any other doubts about our machine, please feel easy to contact with us.
