LTCGS - Series Pharmaceutical Autoclave Autoclave Machine Medicine Sterilizing

LTCGS - Series Pharmaceutical Autoclave Autoclave Machine Medicine Sterilizing

pharmaceutical equipment

pharma machinery

Place of Origin:

ZHEJIANG CHINA

Brand Name:

LTPM CHINA

Certification:

CE certification

Contact Us

Request A Quote
Product Details
Item:
Medicine Sterilizing Pharmaceutical Autoclave
Model:
LTCGS
Capacity:
1.2-5cbm
Material Consist:
Stainless Steel 304
Control:
PLC And Touch Screen
Temperature:
50-150degrees
Steam Pressure:
0.4-0.6Mpa
Designed Pressure:
0.17-0.25Mpa
Working Pressure:
0.15-0.23Mpa
Water Pressure:
0.2-0.4Mpa
Product Description



LTCGS - Series Pharmaceutical Autoclave Autoclave Machine Medicine Sterilizing



Working System and Principle

The requirement and standard on Sterile and non-heating is very high during Biotechnology pharmaceutical production, so they have the more higher requirement on Sterilizer and other accessory equipment. It includes two very important situations we need to know as below:

Sterilizing Media: Moisture Heating Sterilizing is adopting full steam as the sterilizing media, take the advantage of its released heat and moisture while it condensation to make the protein of bacterium in Hydration in order to kill them. During this processing, it must adopts pure non-heating steam to keep the production upto GMP requirement.

Main Machine Material: All of the equipment and containers contact to the sterilizing product must up to Cleaning Standard. Regards to Pure Steam Sterilizing autoclave , all of the connection pipes and containers must be stainless steel 316L.

Feature

LTCGS Series Autoclave Sterilizer is designed strictly according to GMP Standard, adopts horizontal rectangle two layer structure. It works with pure steam as sterilizing media in inner working room. And it use normal hot pot steam pre-heating and drying in jacket layer.

LTCGS Series is suitable for B/C Clean Room where produce sterile clothing, different kinds antibiotic, rubber butyle, flip off cap, injection bottles, etc.

LTCGS Series come with pulsation sterilizing function, besides its processing program can be designed by customer according to different biotechnology production use.

Normal Program and processing:

Normal Equipment and clothing program processing: use pulsation vacuum style to make the inner room high sealed vacuum without any cold air to ensure the steam can be went through uniformly and sterilizing temperature uniformly. After sterilization, vacuum pumping and jacket heating to dry and cooling down the product. The processing program suitable for sterilizing Filling container, sterile clothing in 100 grade Clean room.

Normal Liquid Processing Program: suitable for small unsealed filling liquid sterilization.



Normal Processing Program:

Equipment and clothing processing program:

Auto detecting→ Pre-heating→ Vacuum→ Temp. Rise→ Sterilize→ Dry and cooling→ End

Normal Liquid Processing Program:

Auto Detecting→ Pre-heating → Temp. Rise → Sterilize →Cooling → End

Note: Special Sterilization program can be designed by customer



For More Questions, please contact us by mail or telephone call!

LTPM CHINA, Your Best Pharmaceutical Production Solution!
