ZP - 35D Rotary Tablet Press Machine , Tablet Making Machine Meet GMP Standard

ZP - 35D Rotary Tablet Press Machine , Tablet Making Machine Meet GMP Standard

pharmaceutical process equipment

pharmaceutical equipment

Place of Origin:

ZHEJIANG CHINA

Brand Name:

LTPM CHINA

Certification:

CE

Model Number:

ZP-35D

Contact Us

Request A Quote
Product Details
Product Description



ZP - 35D Rotary Tablet Press Machine , Tablet Making Machine Meet GMP Standard





1. Application:

This machine is a double press automatic rotation for shape-pressing equipment, which have the function of press the grain material or powders to be round or irregular shape tablets, such as candy, calcium tablets double-sides with letter printing and etc. which widely suitable for the Industries of pharmaceutical, Chemical, Foodstuff, Plastic Electronic, Powder Metallurgy and so on.



Features:



1. The material of the machine is made of stainless steel with totally closed, the surface of turntable deal with polished and prevent cross pollution which meet the GMP standard.

2. It is equipped with Organic-glass perspective window for tablet producing observation. Each perspective window could be fully opened and easy for cleaning and maintenance.

3. It is adopts the import Frequency Timing with Electromagnetism Clutch.

4. Driving system is equipped with oil box and running under oil, easy for heat dissipation and wear-resistance.

5. It is equipped with Dust Collector as well, which avoid the dust emission, and recycle to save dust



3. Main Technical Data

Stations (unit) 35 Thickness of the die (mm) 26
Maximum compression (KN) 80 The diameter of the circle of the central pitch of upper &lower punches on the turret 320mm
Max. Diameter of tablet to be produced (mm) 13 Rotary speed of the turret (rpm) 14-35
Max. Filling depth (mm) 15 Capacity of the tablets (max ten thousand tablets/hour) 60,000-147,000pcs
Max. Thickness of tablet (mm) 6 Area to occupy (mm 2 ) 930x950















4. Electronic Parts List: (The electronic Parts brand can be required by you)

Name Model Specification QTY Location
Load Switch VCD0-16 16A 3P 1pcs Schneider, Germany
Breaker DZ47-63/3P-B10 10A 1pcs Delixi, Germany
Breaker DZ47-63/3P-B6 6A 1pcs Delixi, Germany
Transformer JBK-250 0-220-380V/0-24-220V 1set Lianhua, China
Transducer ZVFG9-4055 AC380V 5.5kw 1set Japan
Analog Modules EM235 DC24V 1set Siemens, Germany
Relay HH54P/TP514X AC220V 2pcs Delixi, Germany
Contactor CJX-9/22 AC220V 9A 1pcs Delixi, Germany
Stop Bottom CDY7-11MZS/R Stop and Run 1pcs Delixi, Germany
