PLC Control System Pharmaceutical Dryers Boiling Drying Machine 210kg/h

PLC Control System Pharmaceutical Dryers Boiling Drying Machine 210kg/h

Product Details:

Place of Origin: China
Brand Name: LTPM China
Certification: CE, GMP
Model Number: GFG-100

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Packaging Details: Export standard wooden case
Delivery Time: 25days
Payment Terms: L/C, T/T
Supply Ability: 25sets/month
Get Best Price Contact Now

Detail Information

High Light:

spray drying equipment

,

microwave vacuum drying equipment

Product Description

PLC Control System Pharmaceutical Dryers Boiling Drying Machine 210kg/h



PLC Control System Pharmaceutical Dryers Boiling Drying Machine With Simple Operation





Quick Detail:





Capacity of material bucket(L): 330

Production capacity(kgbatch): 20-100

Temperature of inlet air (℃): indoor ~150℃ adjusting

Pressure(r/min): 0.4

Consumption(kg/h): 210

Weight of main body(kg): 1470

Model: GFG-100





Description:





The structure of fluidization bed is round so as to avoid dead corner;

Inside the hopper there is a srirrer in order to aviod agglomeration of raw material and forming canal of flow;

The granule is discharged through the method of turning over. In this way it is very convenient and full. The discharging system can be designed as request too;

It is operated at the conditions of negative pressure and seal. The air is filtered.

Therefore it is simple in operation and convenient in cleaness. It is an ideal equipment that is conformity with the requirement of GMP.

The drying speed is fast and the temperature is uniform. In general, the drying time is 15-45 minutes each batch.





Applications:





Use screw to sxtrude and vibrate granule and granulate with the method humidity, high speed and mixing;

Suitable for drying humidity block or powder raw material in the fields such as pharmaceutical, foodstuff, feed stuff, chemical industries and so on.





Specifications:





GFG-100 Main Technical Parameters
Model GFG-100
Item
Capacity of material bucket(L) 330
Production capacity(kgbatch) 20-100
Temperature of inlet air (℃) indoor ~150℃ adjusting
Blower Fan Air volume(M3/h) 3620
Air pressure(pa) 7110
Power of Motor(kw) 11
Blending Motor Revolving Speed(r/min) 12
Power of Motor(kw) 1.5
Steam Pressure(r/min) 0.4
Consumption(kg/h) 210
Compressed air Pressure(r/min) 0.5
Consumption(kg/h) 210
Weight of main body(kg) 1470





Competitive Advantage:





1. we have seven technicians who gets passport ready to travel all over world to offer service to you.

2. We have 24hours hot line for Technical Support.

3. We get 18hours internet line for technical support.

4. Video camera in workshop to help you adjust and solve machine problem in working situation.

5. We have Technical Support in below Foreign Cities:

    California (commission worker), Manila and Davao (Distributor), Lima (Agent), Ho Chi Ming and Hanoi         (Agent), Dhaka (Agent), Laho
